ALL PURPOSE CLAMPING (APC) REPLACEMENT PROCEDURES 1.72 All Purpose Clamping (APC) Manual Chapter Issue 1 Nov 16 4. Locate the pneumatic manifolds and the pneumatic connections at the rear of the APC module. 5. Disconnect…

ALL PURPOSE CLAMPING (APC)

REPLACEMENT PROCEDURES

Chapter Issue 1 Nov 16 All Purpose Clamping (APC) Manual 1.71

Mid Rail To remove and replace a mid rail:

1. Slip the transport belt off the associated end and mid rail pulleys.

2. Locate the mid rail pneumatic connections and remove the pneumatic tube

(push the collar on the elbow connector and pull the tube free).

3. Locate the two M3 x6mm board guide retaining screws and remove them.

4. Remove the mid rail board guide.

5. Locate the two M6 x 50mm mid rail screws and remove them. The mid rail

is attached to the chassis and lifts free when the screws are removed.

6. Replacement is the reverse procedure (Steps 1 to 5).

7. To correctly adjust the board guide, perform the Home Position Rail Width

and Board Guide Setting procedure found in the Adjustments and Settings

section of this Chapter.

Centre Section -

APC Module

Where like-for-like replacement is required; this procedure can be used to

remove and replace the centre section of the MTR.

NOTE

If the APC assembly is to be replaced by a different centre section module, all

pneumatic connections must be end terminated or completely removed as

necessary.

1. Locate the APC module (centre section) to be replaced.

2. Slip the transport belt off of the associated left-hand end rail pulley.

3. Isolate the air supply by switching off the isolator switch valve.

Isolator Switch Valve

Location of APC Pneumatic Manifold

ALL PURPOSE CLAMPING (APC)

REPLACEMENT PROCEDURES

1.72 All Purpose Clamping (APC) Manual Chapter Issue 1 Nov 16

4. Locate the pneumatic manifolds and the pneumatic connections at the rear

of the APC module.

5. Disconnect the pneumatic connectors; to remove, push the collar in while

simultaneously pulling the tube out.

6. Remove pneumatic tubing and sensor loom from module mounted cable

ties.

7. Follow sensor loom, and disconnect 8PL235 (front APC module)/8PL236

(rear APC module) from its socket.

8. Locate the two M5 x 20 screws under the APC module, that hold it to the rail.

9. Remove the screws and lift the unit free of the rail.

Retract Sensor

Pneumatic Connections

Retract Sensor Loom (Grey)

3A Clamp Extend (Red)

3B Clamp Retract (Red)

2 Mid Plate Down (Blue)

4B Z Clamp On (Black)

1 Mid Plate Up (Blue)

4A Z Clamp Off (Black)

View on A

View on Underside of APC Module

ALL PURPOSE CLAMPING (APC)

CALIBRATIONS

Chapter Issue 1 Nov 16 All Purpose Clamping (APC) Manual 1.73

CALIBRATIONS

Board Transport

Belt Speed

NOTE

Where the printer is connected to inline equipment, make sure that the FMI

functionality is turned OFF before proceeding.

The front and rear board transport belts are driven independently by two

variable speed motors. Inevitably, one motor drives faster than the other motor.

It is necessary to calibrate these motors so that they drive at the same speed.

Feeder motor speed is measured using a tachometer on the input or output

pulley and adjusted by a potentiometer control on each motor.

1. Remove the right hand safety cover to gain access to the transport belt

motors.

2. Select Maintenance.

3. Select Diagnostics.

4. Use Next or Previous to highlight Rail System.

5. Select Select Module.

6. Use Next or Previous to highlight Rail System.

7. Select Run Diagnost.

The following window is displayed:

NOTE

Belt Speed Calibration figures displayed on this page have no relevance to

the belt speeds on the machine.

8. Select Front L 2 R Speed.

9. Select Incr. or Decr. to start the belts.

Belt Speed Calibration

FRONT L 2 R SPEED

FRONT R 2 L SPEED

REAR L 2 R SPEED

REAR R 2 L SPEED

FRONT L 2 R ALT SPEED

FRONT R 2 L ALT SPEED

REAR L 2 R ALT SPEED

REAR R 2 L ALT SPEED
