Installation and Configuration Guide SIPLACE Explorer 1 Introduction Edition 11/2006 EN 1.1 Scope of Delivery 7 1 Introduction 1.1 Scope of Delivery CD 1 SIPLACE Explorer: 1 – SIPLACE Explorer V2.1 serv er basic package …
Installation and Configuration Guide SIPLACE Explorer
Edition 11/2006 EN
6
Installation and Configuration Guide SIPLACE Explorer 1 Introduction
Edition 11/2006 EN 1.1 Scope of Delivery
7
1 Introduction
1.1 Scope of Delivery
CD 1 SIPLACE Explorer: 1
– SIPLACE Explorer V2.1 server basic package Art. No.: 00169591-05
– SIPLACE Explorer V2.0 - V2.1 server upgrade package Art. No.: 00376950-03
– SIPLACE Explorer V1.2 - V2.1 server upgrade package Art. No.: 00375100-03
– SIPLACE Explorer V2.1 software version description
(English/German) Art. No.: 00193690-05
– Installation and configuration manual
English Art. No.: 00193688-05
German Art. No.: 00193687-05
– Getting started guide
English Art. No.: 00193685-05
German Art. No.: 00193684-05
CD 2 Support Media CD: 1
– The Support Media CD (Art. No.: 00383100-xx) contains additional tools, updates and doc-
umentation for an ideal installation and execution of SIPLACE products.
Please use the document "Navigation Guide for the Installation Procedure of SIPLACE
Software Systems" (Art. No.: 00195050-xx) to navigate through the documentation. The
navigation guide and all related documents are available on the Support Media CD.
Number of CDs: 2 1
1.2 System Requirements
SIPLACE Explorer V2.1 provides various installation variants for the different components: 1
– Factory Layout Central Installation (CI)
– Factory Layout Distributed Installation (DI)
– Single Line Layout
We recommend that you use one of these installation variants for your system. For a detailed de-
scription, please see Section “Standard Installation of SIPLACE Explorer” on page 15. 1
1 Introduction Installation and Configuration Guide SIPLACE Explorer
1.2 System Requirements Edition 11/2006 EN
8
1.2.1 Factory Layout - SIPLACE Explorer Server
1.2.1.1 Hardware
We recommend using an Econel 50. If your system uses other hardware, this hardware must meet
the following requirements: 1
– 3.2 GHz processor
–2 GB RAM
– 80 GB available hard-disk space
Systems using low performance hardware may only deliver reduced process performance. 1
1.2.1.2 Software
– System environment - one of the following versions:
– Windows 2003 server with SP1
– Windows 2003 server R2
– If you are unable to upgrade the system environment:
Windows 2000 server with SP4
NOTE
Although the Windows 2000 server with SP4 is supported by the SIPLACE products, this sys-
tem environment is not the recommended one for SIPLACE products. 1
– Database: Microsoft SQL 2000 with SP4
– Java Runtime Environment (J2SE RTE 5.0 update 7 or SDK 5.0),
included on the installation CD
– Apache Tomcat v.5.5.9 web server,
included on the installation CD
– MS Internet Explorer 6.0 SP1,
included on the installation CD
– MS XML Core Services 4.0 SP 1,
included on the installation CD
– MS Excel 2000 or 2003 (required for the PC on which Factory Reporting is to be installed).
– Acrobat Reader 6.0
included on the installation CD
