INSTRUCTION MANUAL
Volume 4 : Maintenance and Troubleshooting
MODULAR MOUNTER
SIGMA-F8
Before using this service manual, please note the following items.
1. The contents of this service manual are subject to change for improvement
without prior notice. Please pay attention to the latest information that will
be provided or issued by our company.
2. The copyright of the service manual belongs to YAMAHA MOTOR CO.,
LTD.
This service manual shall not in any shape or form, in whole or part, be
reproduced, copied or disclosed to any third party without the written
content of the publisher.
3. Our company shall not be held to any liability for any damages suffered
or incurred by the end user, arising from any operations other than those
(including the purposes and methods) described in this service manual.
Be sure to handle the machine carefully.
4. This service manual neither guarantees any license to industrial property
rights, etc., nor grants any license of such rights.
1204-001
4OM-1733
1
1OM-1733
1204-001
Before Use
We are grateful to you for purchasing Yamaha modular mounter (chip mounter).
This machine can be used to place the chip-type electronic components on PCBs.
This instruction manual describes the functions, handling, and operations of the machine for
those who have nished the basic training of the chip mounter.
Before operating the machine, please read this instruction manual carefully to fully
understand the instructions and precautionary measures for safety purposes.
After reading through this manual, please use this manual as an occasional reference and
keep it within reach.
