4OM-1733

1-4-58

4.13 Ventilating Fans Section

Ventilating Fan

Every 3 Months Cleaning

Required Time: 10 minutes

Ventilating Fan

Every 3 Months Cleaning

Required Time: 10 minutes

Fig. 4A4-69

1211-002

4.13 Fans Section

4OM-1733

1-4-59

4.13.1 Ventilating Fan Cleaning

Cycle : Every 3 Months (Required Time : 10 minutes)

Ventilating Fan

Fig. 4A4-70

Procedure

Suck dirt and dust from the dust lters with a vacuum cleaner.

1211-002

4.13 Fans Section

4OM-1733

1-4-60

4.13.2 Ventilating Fan (Filter) Cleaning

Fig. 4A4-71

Procedure

(1) Remove the exhaust fan (lter) which has been attached with screws (two

locations).

(2) Suck dirk and dust with a vacuum cleaner.

(3) Attach the exhaust fan.

1211-001

4.13 Fans Section
