4OM-1733 1-4-58 4.13 V entilating Fans Section Ventilating Fan Every 3 Months Cleaning Required Time: 10 minutes Ventilating Fan Every 3 Months Cleaning Required Time: 10 minutes Fig. 4A4-69 121 1-002 4.13 Fans Section

4OM-1733

1-4-57

4.12.1 Filter Cleaning

Cycle : Every 3 Months (Required Time : 4 minutes)

Dust Filter

Screw

Fig. 4A4-68

Procedure

(1) Remove the screws (2 locations) xing the dust lter and remove the dust

lter.

(2) Suck dirt and dust with a vacuum cleaner.

(3) Attach the dust lter.

1211-002

4.12 Control Box Section

4OM-1733

1-4-58

4.13 Ventilating Fans Section

Ventilating Fan

Every 3 Months Cleaning

Required Time: 10 minutes

Ventilating Fan

Every 3 Months Cleaning

Required Time: 10 minutes

Fig. 4A4-69

1211-002

4.13 Fans Section

4OM-1733

1-4-59

4.13.1 Ventilating Fan Cleaning

Cycle : Every 3 Months (Required Time : 10 minutes)

Ventilating Fan

Fig. 4A4-70

Procedure

Suck dirt and dust from the dust lters with a vacuum cleaner.

1211-002

4.13 Fans Section
