4OM-1733
1-7-1
1211-002
7. Consumables and Servicing Parts
7. Consumables and Servicing Parts
7.1 List of Consumables
This component list is for the components that would be worn within one year.
When any of these components are to be purchased, contact Marketing Dept. of
YAMAHA MOTOR CO., LTD or our sales agent.
Table 4A7-1
Product Name Part No. Part Name Q'ty
Recommended
Replacement
Cycle
Recommended
number per year
Note (a)
Remarks
Nozzle (HV82C)
Nozzle (HG82C)
KYA-M7782-A0
HV82C---
ASSY_NOZZLE(HV82C) 30 One Year 30
Nozzle (HV13C)
Nozzle (HG13C)
KYA-M7713-A0
HV13C---
ASSY_NOZZLE(HV13C) 30 One Year 30
Nozzle (HV14C)
Nozzle (HG14C)
KYA-M7714-A0
HV14C---
ASSY_NOZZLE(HV14C) 30 One Year 30
Nozzle (HG33C) KYA-M7703-A0
HG33C---
ASSY_NOZZLE(HG33C) 30 One Year 30
Nozzle (HG52C) KYA-M7705-00
HG52C---
ASSY_NOZZLE(HG52C) 30 One Year 30
Nozzle (HG24C) KYA-M7702-A0
HG24C---
ASSY_NOZZLE(HG24C) 30 One Year 30
Vacuum Filter
KYB-M704D-00
225B0572
AIR_CLEAN_EQPT 120 Three Months 240
Nozzle Filter KYA-M7702-10
225A0045
AIR CLEAN EQPT 60 One Week 1440
(720)
Note (e)
Note
(a) The recommended number of pieces is the value for reference only.
(b) Refer to "3. Maintenance Spots" for component replacement procedures.
(c) The recommended replacement cycle does not show the product warranty
period. The recommended replacement cycle varies depending on the
operation condition or operation environment of the product.
(d) In the case of consumables, for the malfunction due to an error in the
manufacturing process, we will replace it by a new one for free of charge.
(e) The recommended replacement cycle for the nozzle lter varies depending
on the nozzle type, pattern program data or operation environment.
(f) The type of nozzle can be identied with the prex of the item name
HV--- : Rigid Nozzle
HG--- : Soft Mounting Nozzle
4OM-1733
1-7-2
1211-002
7.2 List of Servicing Parts
7.2 List of Servicing Parts
This component list is for the components for which maintenance is required in
several years, for your reference.
Note
For the maintenance procedure for the important maintenance components,
consult with our service personnel because high skill is required for such
maintenance.
Table 4A7-2
Block
Name
Product Name Part No. Part Name Q'ty
Recommended #
of years
Note(a)
Remarks
Head
Section
Solenoid Valve KYB-M701U-00
23D10016
ACCESSORY_SV 60 3
Nozzle Shaft
Assembly
KYF-M8651-00
09163K0K
ASSY_SHAFT 60
Sets
-
Hexagon Socket Head
Cap Screw M2×4
90112-02J004
221AA121
ROHS_HEX-SCT 60 - For Nozzle
Shaft Setup
Note (b)
O-Ring for Seal Holder KYB-M704F-00
226A0286
KYB-M7028-00
0916D31E
SEAL
SEAL
60
180
2 (SO-008-13)
(SO-010-12)
Nozzle Shaft Spring KYB-M702F-00
0916DK2D
HOLDER 120 2
Packing for Nozzle
DYR-2.5 Custom
KYB-M704E-00
226A0279
SEAL 120 -
O-Ring for Filter
SO-009-5A
KYB-M702B-00
0916D338
SEAL 120 2
Line Sensor
Linear Measure Light
Projector
KYA-M7017-00
1006D30J
KYA-M8603-00
1006D319
SENSOR_PELEC
SENSOR_PELEC_T
4
4
2
2
Hexagon Socket Head
Cap Screw M1.6×4
90990-01J117
221AA332
ROHS_HEX-SCT 28 - For Diffusion
Plate Setup
Note (b)
Top Block KYA-M7027-00
211G6373
BLOCK 60 -
Cam Follower (
f
2.5) KYB-M704A-00
222H0163
CAM_FOLLOWER 60 -
Hexagon Socket Head
Cap Screw M1.6×3
90990-01J114
221AA330
ROHS_HEX-SCT 60 - For Top Block
Setup Note (b)
Slip Ring KYB-M7027-00
0916D30T
SLIP RING 2 2
4OM-1733
1-7-3
1403-004
7.2 List of Servicing Parts
Table 4A7-2
Block
Name
Product Name Part No. Part Name Q'ty
Recommended #
of years
Note(a)
Remarks
Main Unit Touch Panel Display KYB-M651V-00
1005BA3R
DISPLAY 1 3
Vacuum Pump KYB-M861C-00
1005BB00
VACUUM_PUMP 1 -
Transfer
Unit
Flat Pulley KYA-M914U-00
1007A00A
PULLEY_FLAT 8 5
Timing Belt KYA-M9152-00
1007A022
BELT_TIMING 4 1
Cylinder KYA-M912L-00
1007A00B
CYLINDER 3(4) 3 Note (d)
Cylinder KYA-M912P-00
1007A00U
CYLINDER 6 3
Cylinder KYA-M912S-00
1007A011
CYLINDER 2 3
Timing Pulley KYB-M91AL-00
1007A097
PULLEY_TIMING 32 5
Cutter
Section
Cutter Block ASSY KYF-M865R-00
0920711W
ASSY_CUTTER_1 2 2
Note
(a) The recommended year of pieces is the value for reference only.
(b) Do not reuse any bolt removed during maintenance.
(c) The linear measure consists of the controller and head (light projector and
light receiver) as a set.
The head (light projector) of the linear measure can be replaced as a single
linear measure light projector.
(d) The gures for the Q'ty to be used in the brackets, show the values for the
Y510 mm Single Transfer Unit (Option).
