4OM-1733
1-5-6
1208-001
5.5 Cleaning of high-speed nozzle hole part with pin gauge
5.5 Cleaning of high-speed nozzle hole part with pin gauge
After the ultrasonic cleaning, conrm the clog of the nozzle hole with the
magnifying glass.
When the clog is conrmed, clean it with the pin gauge.
•
Select pin gauge
The pin gauge used is different depending on the kind of a high-speed nozzle.
Please select it referring to the combination shown next.
Unit : mm Table 4A5-1
Nozzle ID
Diameter
(center hole
diameter)
Diameter
(minimum hole
diameter)
Pin gauge
size
Part No.
Direction of pin
gauge insertion
Nozzle Tip
Cleaning Jig
HG24C
f
0.1
f
0.08
f
0.08
KYB-M384L-00
0942J1A9
Nail side, Head
side
KYB-M384P-00
0942J1AH
HG33C
f
0.2
f
0.08
f
0.12
KYF-M861K-00
0942J1AC
Nail side, Head
side
KYB-M384R-00
000942J1A5
HG52C
f
0.4
f
0.25
f
0.2
KYF-M861L-00
0942J1AD
Nail side, Head
side
HG82C
f
0.7
f
0.35
f
0.3
KYF-M862U-00
0942J1AE
Head side (a)
HV82C
f
0.7
f
0.35
f
0.3
KYF-M862U-00
0942J1AE
Nail side, Head
side
HG13C
f
0.9
f
0.9
f
0.6
KYB-M384M-00
0942J1AF
Head side (a)
HV13C
f
0.9
f
0.9
f
0.6
KYB-M384M-00
0942J1AF
Nail side, Head
side
HG14C
f
1.1
f
1.1
f
0.8
KYB-M384N-00
0942J1AG
Head side (a)
HV14C
f
1.1
f
1.1
f
0.8
KYB-M384N-00
0942J1AG
Nail side, Head
side
HG15C
f
2.0
f
1.1
f
0.8
KYB-M384N-00
0942J1AG
Head side (a)
HV15C
f
2.0
f
1.1
f
0.8
KYB-M384N-00
0942J1AG
Nail side, Head
side
Note
(a) Pin gauge can not be inserted from nail side.
4OM-1733
1-5-7
1208-001
5.5 Cleaning of high-speed nozzle hole part with pin gauge
•
Method of cleaning high-speed nozzle hole
Procedure
(1) Firmly have the high-speed nozzle as shown in the following photograph
and insert it while matching a pin gauge center axis to a center axis of
a high-speed nozzle.
Notice
When a center axis shifts, the head might be damaged.
Pin gauge
High-speed nozzle
Fig. 4A5-5
(2) Put out the pin gauge from the head of the high-speed nozzle.
High-speed nozzle
Pin gauge
Fig. 4A5-6
4OM-1733
1-5-8
1208-001
5.5 Cleaning of high-speed nozzle hole part with pin gauge
(3) Move the pin gauge to the direction of the length hand of pick-up hole and
remove the internal clog.
Pin gauge
High-speed nozzle
Fig. 4A5-7
(4) Blow air and blow away removed dirt (Stick and remove the ne dirts of the
high-speed nozzle head by the masking tape).
High-speed nozzle
Masking tape
Fig. 4A5-8
