Safety Precautions Safe-26 1OM-1733 1208-003 5. Alert Labels (13) Pay attention to the moving mechanisms! Do not put your hand in the moving area. Otherwise, your hand might be caught in the moving area and injured. View…
Safety Precautions
Safe-25
1OM-1733
1208-003
5. Alert Labels
(13)
Pay attention to the moving
mechanisms!
Do not put your hand in the moving area.
Otherwise, your hand might be caught in
the moving area and injured.
View V-V
Fig. X14
Safety Precautions
Safe-26
1OM-1733
1208-003
5. Alert Labels
(13)
Pay attention to the moving
mechanisms!
Do not put your hand in the moving area.
Otherwise, your hand might be caught in
the moving area and injured.
View W-W
Fig. X15
Safety Precautions
Safe-27
1OM-1733
1403-005
5. Alert Labels
(20)
Do not touch your hand to the Reference Mark Block.
When a strong force is given to the reference mark block,
it might be deformed.
PEC Recognition Camera
Fig. X16
