4OM-1733 1-1-4 • V acuum T weezers Use a pair of vacuum tweezers on the market. (Handy T ype) (Motor-Driven T ype) V arious T ypes of V acuum T weezers Fig. 4A1-3 1208-002 1.2 Preparation for Maintenance
4OM-1733
1-1-3
•
Air Gun
Do not use the air gun for any spots other than the specied ones.
If dirt and dust are dispersed, they may adhere to the sensors and moving
mechanisms, causing the machine to break down.
Fig. 4A1-1
•
Vacuum Cleaner
If the suction hole of the vacuum cleaner is changed to a smaller one, some
spots can be cleaned more easily.
•
Cleaning Paper
Use the attached pieces of paper (standard accessory).
•
Lens Cleaning Cloth
Use the attached pieces of cloth (standard accessory).
Fig. 4A1-2
1208-002
1.2 Preparation for Maintenance
4OM-1733
1-1-4
•
Vacuum Tweezers
Use a pair of vacuum tweezers on the market.
(Handy Type)
(Motor-Driven Type)
Various Types of Vacuum Tweezers
Fig. 4A1-3
1208-002
1.2 Preparation for Maintenance
4OM-1733
1-1-5
1.2.2 Preparation for Lubrication
Prepare for the specied types of grease and lubrication tools.
Note
Upper part numbers in the below table are YAMAHA part numbers, lower ones
are HITACH equivalents.
SpeciedGreases
•
DAPHNE EPONEX GREASE No. 1 (IDEMITSU KOSAN)
•
MOLYNOC GREASE AP1 (JX Nippon Oil & Energy)
•
BARRIERTA IEL/V (NOK Klueber CO.,Ltd.)
Note
Before lubrication, wipe off old grease. Otherwise, the effect of grease and oil
will decrease.
Same Types of Lubricants
•
Grease Types equivalent to DAPHNE EPONEX GREASE No. 1
(IDEMITSU KOSAN)
Table 4A1-1
Grease Names Makers
Alvania Grease No. 1 Showa Shell Sekiyu K.K
Multinoc Grease 1 JX Nippon Oil & Energy
Jomo Lisonix Grease No. 1 JX Nippon Oil & Energy
Dynamax No. 1 COSMO OIL LUBRICANTS
Lithtan 1 Exxon Mobil Corporation
MP Grease No. 1 KYGNUS
Gemico MP-1 Tonen General Sekiyu K.K
Multemp PS1 KYODOH YUSHI CO., LTD.
•
Grease Types equivalent to MOLYNOC GREASE AP1
(JX Nippon Oil & Energy)
Table 4A1-2
Grease Names Makers
DAPHINE Grease M No. 1 Idemitsu Kosan Co., Ltd.
Jomo Lisonix Grease M No. 1 JX Nippon Oil & Energy
COSMO MOLYBDEN GREASE
No. 1
COSMO OIL LUBRICANTS
BEACON Q2 Exxon Mobil Corporation
Gemico MD2 Tonen General Sekiyu K.K
M5 GREASE 1 KYGNUS
