Safety Precautions Safe-23 1OM-1733 1208-001 Rear Side of Machine (4) Fig. X11 Rear Side of Machine with Lower Cover (16) Fig. X12 5. Alert Labels
Safety Precautions
Safe-22
1OM-1733
1208-001
5. Alert Labels
Front Side of Machine
(6)
(16)
Fig. X9
Front Side of the Machine
with Lower Cover
(4)
Fig. X10
Safety Precautions
Safe-23
1OM-1733
1208-001
Rear Side of Machine
(4)
Fig. X11
Rear Side of Machine
with Lower Cover
(16)
Fig. X12
5. Alert Labels
Safety Precautions
Safe-24
1OM-1733
1208-003
5. Alert Labels
(2)
(13)
(12)
(15)
(15)
Pay attention to the moving
mechanisms!
Do not put your hand in the moving area.
Otherwise, your hand might be caught in
the moving area and injured.
(14)
Do not put anything on it
This might damage the machine.
Fig. X13
