Student Guide HS-50 Advanced I Edition 06/2002
11 Pneumatic Cutter and Empty-Tape Duct
33
11.6.5 Exchanging the Control Unit
Fig. 11.6.5 Exchanging the Control Unit, Allocation of the Plug-and-Socket Connections
Key:
1. Drive of solenoid valve for cylinder 2 (left)
2. Drive of solenoid valve for cylinder 1 (right)
3. to the proximity switch on cylinder 2, FRONT
4. to the proximity switch on cylinder 1, FRONT
5. to the proximity switch on cylinder 2, BACK
6. to the proximity switch on cylinder 1, BACK
7. Cutter power supply (only busy on S-23 and F5)
8. Drive of cutter (only busy on S-23 and F5)
9. Service plug (to be used exclusively by Siemens)
10. CAN bus
11. Power supply
12. Spring-mounted elements to disconnect the control board box
13. Support bar
14. Cover
15. Fixing pedestal adhesive type (LH and RH) with cable tie
Relieve tensile stress on cable/plug-and-socket connections.
16.Coding plug
Edition 06/2002 Student Guide HS-50 Advanced I
11 Pneumatic Cutter and Empty-Tape Duct
34
WARNING
You might cut yourself on the blades and the tape deflector.
Never reach into the pneumatic cutter from below or into the empty-tape duct from above. 11
The cutter remains installed in the machine. 11
à Turn the machine and then the compessed air ON.
à Disconnect the movable component changeover table from the machine and move it out of the
machine.
à Turn the machine OFF, disconnect the machine from the mains and turn off the flow of com-
pressed air at the compressed air. Actuate the needle valve on the compressed air unit to bleed
the compressed air lines (see DANGER text in Section 11.1).
à Remove the cover from the control board (see Fig. 11.6.5 -> 14).
à Carefully undo the cable ties (left and right) on the outside of the control board box (see
Fig. 11.6.6 -> 10).
-> Do not damage the cables in this process.
à Mark the allocation of all plug-and-socket connectors and disconnect all plug-and-socket con-
nections on the control board (se Fig. 11.6.5).
à Disconnect the control unit (box) from the support bar by pushing both of the spring-mounted
elements away from the bar (see Fig. 11.6.5 -> 12, 13).
à Install the new control unit (Item no.: see Section 11.2), correctly rotated and positioned, on the
bar and engage the unit.
à Mount an adhesive fixing pedestal for cable ties (see Section 11.2 for Item no.) on the outside
LH and RH side of the control board box (see Fig. 11.6.6 -> 10 for location).
à Restore all plug-and-socket connections in the correct allocation (see Fig. 11.6.5).
à Use a cable tie to fasten the cables running to the LH and RH side of the cable pit to the fixing
pedestal (on control board box). The strain on the cables/plug-and-socket connections must
be relieved (see Fig. 11.6.6 -> 8).
à Place the cover back on the control board.
à Perform the appropriate “Final Steps” (see Section 11.6.11).
Student Guide HS-50 Advanced I Edition 06/2002
11 Pneumatic Cutter and Empty-Tape Duct
35
11.6.6 Exchanging the Solenoid Valve on Left or Right (and/or Cable)
WARNING
You might cut yourself on the blades and the tape deflector.
Never reach into the pneumatic cutter from below or into the empty-tape duct from above. 11
The cutter remains installed in the machine. 11
à Turn the machine and then the compressed air ON.
à Disconnect the movable component changeover table from the machine and move it out of the
machine.
à Turn the machine OFF, disconnect the machine from the mains and turn off the flow of com-
pressed air at the compressed air. Actuate the needle valve on the compressed air unit to bleed
the compressed air lines (see DANGER text in Section 11.1).
Key to Fig. 11.6.6 (right):
1. Solenoid valve for cylinder 1, incl. mounting strap
2. Solenoid valve for cylinder 2, incl. mounting strap
3. to the plug-and-socket connection of the appropriate solenoid valve
4. Screws for fastening the solenoid valve: 2 socket hex head cap screws each, M3 x 6
5. Cover of the cable pit
6. Compressed air hoses for cylinder 1
7. Compressed air hoses for cylinder 2
8. No strain on cable/plug-and-socket connections
9. Cover
10. Fixing pedestal, adhesive type, with cable tie (LH and RH)
11. Plug-and-socket connection on the solenoid valve
