Error ID Error Name, Description, Cause, and Remedy

403E01 Detecting Lower Magazine rack shutter (Block1)

Open the rack shutter while lower elevator is moving.(Block1)[B15521][B15523]

[B15525]

Check out the sensor (B15521, B15523, B15525) of closing magazine rack

shutter.

403F01 Detecting Upper Magazine rack shutter (Block1)

Open the rack shutter while upper elevator is moving.(Block1)[B15527][B15529]

[B15531]

Check out the sensor (B15527, B15529, B15531) of closing magazine rack

shutter.

404001 Lower magazine positioning error(Block1)

Lower magazine positioning error(Block1) [B15526]

Check Magazine Clamp.

404101 Upper magazine positioning error(Block1)

Upper magazine positioning error.(Block1) [B15532]

Check Magazine Clamp.

404201 Shut-o Motor Breaker for Tray (Block1)

Tripped circuit breaker of motor (Block1).

Please turn on again after turning o and cancelling Trip mode.

404301 Shut-o safety relay of Elevator(Lower) (Block1)

Cut o safety relay of lower elevator (Block1).

Check the main circuit and safety door.

404401 Shut-o safety relay of Elevator(Upper) (Block1)

Cut o safety relay of upper elevator (Block1).

Check the main circuit and safety door.

404501 Elevator Unit Clamp released (Block1)

Released clamp of elevator unit (Block1)[B15426, B15428]

Check out Elevator unit clamp sensor(B15426, B15428).

404601 Detecting pickup miss cmpnt of Tray Feeder Cart (Block1)

Detecting pickup miss cmpnt(Block1) [B15412]

1. Open the cover.

2. Conrm suppressor, Disengaged Latch and remove the Pickup miss cmpnt.

3. Close the cover and then Lock it.

404701 Detecting Feeder Disengaged Latch of Tray Feeder Cart(Block1)

Feeder Disengaged Latch is detected.(Block1)[B15412]

1. Open the cover.

2. Conrm suppressor, Disengaged Latch and remove the Pickup miss cmpnt.

3. Close the cover and then Lock it.

404801 Detecting Emergency Stop(Block2)

Emergency stop(Block2) is detected

Please turn on the main body and operate it.

404901 Tray Safety Door(Lower)(Block2)

Safety door(Lower) of tray feeder unit opened.(Block2)[S0501]

Please close the safety door(lower) and operate it.

3.1 Safety Device

4OM-1840

3-3-151604-001

Error ID Error Name, Description, Cause, and Remedy

404A01 Tray Safety Door(Upper)(Block2)

Safety door(Upper) of tray feeder unit opened.(Block2)[S0502]

Please close the safety door(upper) and operate it.

404B01 Tray Safety Door(Center)(Block2)

Safety door(Center) of tray feeder unit opened.(Block2)[S0503]

Please close the safety door(center) and operate it.

404C01 Pallet Chuck Claw(Block2)

Pallet Chuck Claw opened while elevator is moving.(Block2)[B15407, B15408]

Check out detection Sensor of closing Chucking lever of pallet (B15407, B15408).

404D01 Pallet ying away(Block2)

Pallet ying away during elevator moving.(Block2)[B15406]

Check out detecttion sensor of breaking out Pallet (B15406) and position of Pallet.

404E01 Detecting pickup miss cmpnt on Tray Pallet (Block2)

Pickup misscmpnt on the Pallet is detected.(Block2) [B15417]

Open the main cover and remove pickup miss components on the Tray Pallet.

404F01 Detecting pickup miss cmpnt on Tray Pallet (Block2)

Pickup miss cmpnt on the Pallet is detected.(Block2) [B15418]

Open the main cover and remove pickup miss components on the Tray Pallet.

405001 Detecting pickup miss cmpnt on Tray Pallet (Block2)

Pickup miss components on the Pallet is detected.(Block2) [B15419]

Open the main cover and remove pickup miss components on the Tray Pallet.

405101 Detecting lower Magazine rack shutter (Block2)

the rack shutter opening is detected during lower elevator moving.(Block2)

[B15521, B15523,B15525]

Check out the sensor of closing magazine rack shutter (B15521, B15523,

B15525).

405201 Detecting upper Magazine rack shutter (Block2)

the rack shutter opening is detected during upper elevator moving.(Block2)

[B15527, B15529,B15531]

Check out the sensor of closing magazine rack shutter (B15527, B15529,

B15531).

405301 Lower magazine positioning error (Block2)

Lower magazine positioning error.(Block2)[B15526]

Conrm Magazine Clamp.

405401 Upper magazine positioning error (Block2)

Upper magazine positioning error.(Block2)[B15532]

Conrm Magazine Clamp.

405501 Shut-o Motor Breaker for Tray (Block2)

Tripped circuit breaker of motor (Block2)

Please turn on again after turning o and cancelling Trip mode.

405601 Shut-o safety relay of Elevator(Lower) (Block2)

Cut o safety relay of lower elevator (Block2).

Conrm the main circuit and safety door.

3.1 Safety Device

4OM-1840

3-3-161604-001

Error ID Error Name, Description, Cause, and Remedy

405701 Shut-o safety relay of Elevator(Upper) (Block2)

Cut o safety relay of upper elevator (Block2).

Conrm the main circuit and safety door.

405801 Released Elevator unit clamp(Block2)

Released elevator unit clamp(Block2)[B15426, B15428]

Conrm the Elevator Unit Clamp Sensor(B15426, B15428).

405901 Detecting pickup miss cmpnt of Tray Feeder Cart (Block2)

Pickup miss components was detected(Block2). [B15412]

1.Open the cover.

2.Conrm suppressor, Disengaged Latch and remove the Pickup miss cmpnt.

3.Close the cover and then lock it.

405A01 Detecting Feeder Disengaged Latch of Tray Feeder Cart(Block2)

Feeder Disengaged Latch is detected (Block2).[B15412]

1.Open the cover.

2.Conrm suppressor, Disengaged Latch and remove the Pickup miss cmpnt.

3.Close the cover and then lock it.

406701 Detecting pickup miss cmpnt on Tray Pallet (Block1)

Pick-up miss cmpnt is detected on Tray pallet (Block1)
