Error ID Error Name, Description, Cause, and Remedy
42a105 Detect Suttle Conveyor Sensor in Input side
PCB is detected from Decrease Sensor after nishing completely.
Please remove PCB from Shuttle Conveyor.
42a106 Detect Suttle Conveyor Sensor in Input side
PCB is not detected from Decrease Sensor after nishing completely.
Please conrm whether PCB is detected properly. And conrm whether Sensor
did not break down.
42a107 Detect Suttle Conveyor Sensor in Input side
PCB is detected from Stop Sensor after nishing completely.
Please remove PCB from Shuttle Conveyor.
42a108 Detect Suttle Conveyor Sensor in Input side
PCB is not detected from Stop Sensor after nishing completely.
Please conrm whether PCB is detected properly. And conrm whether Sensor
did not break down.
42a109 Detect Suttle Conveyor Sensor in Input side
PCB is detected from Shuttle Conveyor.
Please remove PCB from Conveyor.
42a10a Detect Suttle Conveyor Sensor in Input side
PCB is not detected from Shuttle Conveyor.
Please conrm whether PCB is detected properly. And conrm whether Sensor
did not break down.
42a10b Detect Suttle Conveyor Sensor in Input side
PCB has not got to shuttle Conveyor from Input Machine.
PCB from Input Machine is not transferred.
Please conrm whether PCB on the conveyor for Input machine is caught
42a10c Detect Suttle Conveyor Sensor in Input side
PCB is still on Shuttle conveyor.
To insert into inner Machine is not completed. Please check PCB position.
42a10d Detect Suttle Conveyor Sensor in Input side
PCB on Shuttle conveyor is gone.
It is possible to operate continuously.
Please conrm whether PCB went o its position if PCB is not removed on
purpose.
42a10e Detect Suttle Conveyor Sensor in Input side
PCB on Shuttle conveyor is changed.
PCB is inserted while not possible to be inserted. Please remove inserted PCB.
42a10f Detect Suttle Conveyor Sensor in Input side
The Sensor of Shuttle Conveyor is detected from both sides.
There is a possibility that two pieces of PCB are inserted. Please remove an
uncertain PCB. Please setup Timing to transfer PCB from Input machine.
