Error ID Error Name, Description, Cause, and Remedy
42320f Error in NL-L2 axis
System Error on NL-L2 axis
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
423210 Error in NL-L2 axis
Communication Error on NL-L2 axis
1. Conrm connection to communication cable.
2. Conrm Power supply(24V).
3. Conrm the communication setting of PCI board.
4. Conrm the address of driver and communication rate setting.
5. Conrm Firmware of Driver.
423301 Error in NA-L1 axis
Zeroing Error on NA-L1 axis
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423302 Error in NA-L1 axis
Out-of-Control on NA-L1axis was detected
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423303 Error in NA-L1 axis
Error in motor power voltage of NA-L1 axis
Motor power voltage dropped. Check out the Power supply line(48V Line)
423304 Error in NA-L1 axis
STP input on NA-L1 axis was detected
STP input is detected. The function to stop motor by Hard signal.
423305 Error in NA-L1 axis
Over-current on NA-L1 axis
Abnormal current in motor output line was detected. Conrm the motor wiring,
supplying power.
423306 Error in NA-L1 axis
Limit sensor(+) on NA-L1 axis was detected
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423307 Error in NA-L1 axis
Limit sensor(-) on NA-L1 axis was detected
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423308 Error in NA-L1 axis
Motor disconnection of NA-L1axis was detected
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
423309 Error in NA-L1 axis
Error in control power voltage of NA-L1 axis
Control power for driver dropped. Check out the Power supply line.(24V Line)
3.3 Conveyor
4OM-1840
3-3-361604-001
Error ID Error Name, Description, Cause, and Remedy
42330a Error in NA-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42330b Error in NA-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42330c Error in NA-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42330d Error in NA-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42330e Error in NA-L1 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42330f Error in NA-L1 axis
System Error on NA-L1 axis
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
423310 Error in NA-L1 axis
Communication Error on NA-L1 axis
1. Conrm connection to communication cable.
2. Conrm Power supply(24V).
3. Conrm the communication setting of PCI board.
4. Conrm the address of driver and communication rate setting.
5. Conrm Firmware of Driver.
423401 Error in NA-L2 axis
Zeroing Error on NA-L2 axis
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423402 Error in NA-L2 axis
Out-of-Control on NA-L2 axis was detected
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423403 Error in NA-L2 axis
Error in motor power voltage of NA-L2 axis
Motor power voltage dropped. Check out the Power supply line(48V Line)
423404 Error in NA-L2 axis
STP input on NA-L2 axis was detected
STP input is detected. The function to stop motor by Hard signal.
423405 Error in NA-L2 axis
Over-current on NA-L2 axis
Abnormal current in motor output line was detected. Conrm the motor wiring,
supplying power.
3.3 Conveyor
4OM-1840
3-3-371604-001
Error ID Error Name, Description, Cause, and Remedy
423406 Error in NA-L2 axis
Limit sensor(+) on NA-L2 axis was detected
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423407 Error in NA-L2 axis
Limit sensor(-) on NA-L2 axis was detected
No use the function. Please check the driver-axis setting in a case error is
detected because there is a possibility of error of driver-axis setting.
423408 Error in NA-L2 axis
Motor disconnection of NA-L2 axis was detected
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
423409 Error in NA-L2 axis
Error in control power voltage of NA-L2 axis
Control power for driver dropped. Check out the Power supply line.(24V Line)
42340a Error in NA-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42340b Error in NA-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42340c Error in NA-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42340d Error in NA-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42340e Error in NA-L2 axis
Reserved Code
Reserved Function of driver. Please make inquiries when error is detected.
42340f Error in NA-L2 axis
System Error on NA-L2 axis
System Error of internal driver. Driver error is supposed if this problem happens
frequently.
423410 Error in NA-L2 axis
Communication Error on NA-L2 axis
1. Conrm connection to communication cable.
2. Conrm Power supply(24V).
3. Conrm the communication setting of PCI board.
4. Conrm the address of driver and communication rate setting.
5. Conrm Firmware of Driver.
423501 Error in NR-L1 axis
Zeroing Error on NR-L1 axis
No use the function. Please check the driver-axis setting when error is detected
because there is a possibility of error of driver-axis setting.
3.3 Conveyor
4OM-1840
3-3-381604-001
