Error ID Error Name, Description, Cause, and Remedy
4b4f01 No cmpnt after ux dispensing(Sensor)
Could not detect cmpnt on nozzle tip. There is a possibility that picked-up cmpnt
is fallen on the drum.
Please detach ux dispensing unit, and then remove components on the drum.
4b5001 No cmpnt after ux dispensing(Recog)
Could not detect cmpnt on nozzle tip. There is a possibility that picked-up cmpnt
is fallen on the drum.
Please detach ux dispensing unit, and then remove components on the drum.
4b5101 Recycle conveyor error
It was impossible to detect the Cmpnt passing the passing check sensor.
Please remove all the components on the recycle conveyor.
4b5102 Recycle conveyor error
Cmpnt remains on the recycle conveyor(Block1).
Please restart Auto Opn after removing the remained cmpnt.
4b5103 Recycle conveyor error
Cmpnt remains on the recycle conveyor(Block2).
Please restart Auto Opn after removing the remained cmpnt.
4b5201 Impossible disposal(Disposal box)
It is impossible to send cmpnt to disposal box for discard because it is too large.
Please carry out disposal after inserting the recycle conveyor.
4b5301 Disposal error
Error in the disposal
Please retry to dispose. Please remove the cmpnt in the head and restart up if
there is still an error.
4b5401 Library tape width check
The tape width in library and the feeder are not in agreement.
Please check the library and feeder.
-----
4b5501 Library Feed Pitch check
Library Feed Pitch diers from Feeder. Please check Library and Feeder.
-----
4b5601 Head type error
The set type and the installed type for head1 are dierent.
Please restart it after matching a set type to the head type.
Please check the DIP switch on installed PCB on the head after shut down.
There is possibility that communication system has error.
4b5602 Head type error
The set type and the installed type for head2 are dierent.
Please restart it after matching a set type to the head type.
Please check the DIP switch on installed PCB on the head after shut down.
There is possibility that communication system has error.
4b5701 Library cmpnt carriage type error
There are errors of the cmpnt carriage type of the library.
Please check the library, and then do Chng. program.
3.8 Others
4OM-1840
3-3-1041604-001
Error ID Error Name, Description, Cause, and Remedy
4b5801 Joint detect
A joint is detected.
Please perform consistency check.
4b5901 LISA Communication error
LISA communication has errors.
Please check the followings, PC condition, Hub condition and connection
condition to LAN cable for LISA.
4b5a01 Warning about Maintenance
The total number of the feeder shot exceeded the setting value. It is time to
perform the feeder maintenance.
-----
4b5a02 Warning about Maintenance
The feeder adsorption rate decreased and exceeded the previous notice setting
number. It is time to perform the feeder maintenance.
-----
4b6001 Time Synchronization error
The time dierence with the server device is 24 hours and more. Time
synchronization has been stopped.
There is a possibility that the battery of CPU board was dead.
Please inspect the battery of CPU board.
Please check the system time.
4b6101 Bowl Feeder power shut-o
Main power breaker of bowl feeder(Block1) is shut o.
Please check the power breaker of bowl feeder(Block1).
4b6102 Bowl Feeder power shut-o
Main power breaker of bowl feeder(Block2) is shut o.
Please check the power breaker of bowl feeder(Block2).
4b6201 Feeder information output error
It is a folder to output loaded feeder information le.
The server of output folder is not connected. Please take out and take in a feeder
after checking connection status.
-----
4b6202 Feeder information output error
Could not output loaded feeder information le.
The server of output folder is not connected. Please take out and take in a feeder
after checking connection status.
-----
4b6203 Feeder information output error
Could not delete output loaded feeder information le.
The server of output folder is not connected. Please take out and take in a feeder
after checking connection status.
-----
3.8 Others
4OM-1840
3-3-1051604-001
Error ID Error Name, Description, Cause, and Remedy
4b7201 BCD PP Change error
Disconnected server for BCD PP change reference folder. Please checking
connection status.
-----
4b7202 BCD PP Change error
Could not output pattern program list le to server for BCD PP change reference
folder. Please checking connection status and le of shared folder.
-----
4b7203 BCD PP Change error
Could not delete pattern program list le on server for BCD PP change reference
folder. Please checking connection status and le of shared folder.
-----
4b7204 BCD PP Change error
The PP info le is not found. Please register the PP info le with the GCM server.
-----
4b7205 BCD PP Change error
The format is abnormal of the PP info le (Placement OK/NG data is abnormal).
-----
4b7206 BCD PP Change error
The format is abnormal of the PP info le (Placement pattern ID name is
abnormal).
-----
4b7207 BCD PP Change error
The format is abnormal of the PP info le (Placement OK/NG data:NG).
-----
T4C12
3.8 Others
4OM-1840
3-3-1061604-001
