3.8 Others
Error ID Error Name, Description, Cause, and Remedy
4b0201 Feeder communication Error.
Communication with the feeder has an error.
Please check the number of component remain.
4b0204 Feeder communication Error.
Communication with feeder was not completed within predetermined time. (Please
take out and insert feeder.)
-----
4b0205 Feeder communication Error.
Failed in processing information read, Please put the Cart down, or pull out and
insert Feeder.
-----
4b0206 Feeder communication Error.
Failed in Program-changed. Please put the Cart down, or pull out and insert
Feeder.
-----
4b0207 Feeder communication Error.
Failed in Splicing survey setup. Please put the Cart down, or pull out and insert
Feeder.
-----
4b0208 Feeder communication Error.
Cannot send it because of Error of Serial Communication process. Please put the
Cart down, or pull out and insert Feeder.
-----
4b0209 Feeder communication Error.
-----
Please take out a feeder once, and then take it in
4b0302 Feeder Base
The feeder unclamp operation was not completed within predetermined time.
-----
4b0304 Feeder Base
The feeder clamp operation was not completed within predetermined time.
-----
4b0305 Feeder Base
The feeder base ascent operation was not completed within predetermined time.
Check the feeder base upper limit position.
4b0306 Feeder Base
The feeder base descent operation was not completed within predetermined time.
Check the feeder base lower limit position.
4b0307 Feeder Base
The connector (Block1) for the feeder base worked o. Do not remove the
connector during feeder base ascent.[B0916]
Connect the connector (Block1) for the feeder base to the machine main body.
3.8 Others
4OM-1840
3-3-861604-001
Error ID Error Name, Description, Cause, and Remedy
4b0308 Feeder Base
The connector (Block2) for the feeder base worked o. Do not remove the
connector during feeder base ascent.[B0916]
Connect the connector (Block2) for the feeder base to the machine main body.
4b0310 Feeder Base
The power was not turned on, or emergency stop was detected.
Please turn on the machine after conrm that Emergency Stop button is not
pressed.
4b0311 Feeder Base
Feeder Cart could not be detected.
Please execute operation again after setting Feeder Cart in predetermined place.
Please conrm whether it set in if the set is already done well.
4b0312 Feeder Base
Connector of Feeder Cart is not connected
Please execute operation again after connecting connector of Feeder Cutter.
4b0313 Feeder Base
NL-axis interlock was detected
Please execute zeroing when NL-axis is fallen.
4b0314 Feeder Base
Error in Feeder Base movement
----
4b0315 Feeder Base
Time-out in Clamp Movement of Elevator Unit
----
4b0316 Feeder Base
Time-out in Unclamp Movement of Elevator Unit
----
4b0317 Feeder Base
Illegal current position of Feeder base (Block1)
Please conrm Feeder base, and the sensor of Cylinder Upper limit
detection[B0614], Cylinder Lower limit detection[B0615].
4b0318 Feeder Base
Illegal current position of Feeder base (Block2)
Please conrm Feeder base, and the sensor of Cylinder Upper limit
detection[B0614], Cylinder Lower limit detection[B0615].
4b0319 Feeder Base
Positioning dropping prevention stopper(Block1) cannot cancel lock.
Please conrm the state of Feeder base and detect sensor of positioning drop
prevention lock[B0912][B0913]
4b031A Feeder Base
Positioning dropping prevention stopper(Block2) cannot cancel lock.
Please conrm the state of Feeder base and detect sensor of positioning drop
prevention lock[B0612][B0613]
3.8 Others
4OM-1840
3-3-871604-001
Error ID Error Name, Description, Cause, and Remedy
4b031B Feeder Base
Positioning dropping prevention stopper(Block1) cannot lock.
Please conrm the state of Feeder base and detect sensor of positioning drop
prevention lock[B0912][B0913]
4b031C Feeder Base
Positioning dropping prevention stopper(Block2) cannot lock.
Please conrm the state of Feeder base and detect sensor of positioning drop
prevention lock[B0612][B0613]
4b031D Feeder Base
Cart rising stopped(Block1).
Cannot release the safety cover for the cart in the opposite side is in process.
The process stopped because there is a possibility that something is placed
between Cart and the safety cover.
-----
4b031E Feeder Base
Cart rising stopped(Block2).
Cannot release the safety cover for the cart in the opposite side is in process.
The process is stopped because there is a possibility that something is placed
between Cart and the safety cover.
-----
4b031F Feeder Base
Failed that Automatic safety cover opening starts up. The process is stopped
because there is a possibility that something is placed between Cart and the
safety cover.
-----
4b0320 Feeder Base
Automatic safety cover opening is not completed in predetermined time. The
process is stopped because there is a possibility that something is placed
between cart and the safety cover.
-----
4b0321 Feeder Base
Failed in Automatic safety cover opening (Release Lock).
The process is stopped because there is a possibility that something is placed
between cart and the safety cover.
-----
4b0322 Feeder Base
Cannot distinguish a cart(Block1). Please operate it again.
-----
4b0323 Feeder Base
Cannot distinguish a cart(Block2). Please operate it again.
-----
4b0501 Manual alignment Error
Operation was not completed within predetermined time.
-----
3.8 Others
4OM-1840
3-3-881604-001
