1.2.2 Preparation for Lubrication
Note
Upper part numbers in the below table are YAMAHA part numbers, lower ones
are HITACH equivalents.
Specied Greases
•
DAPHNE GREASE MP No. 1 (IDEMITSU KOSAN)
•
•
BARRIERTA IEL/V (NOK Klueber CO.,Ltd.)
Note
will decrease.
Same Types of Lubricants
•
Grease Types equivalent to DAPHNE GREASE MP No. 1
(IDEMITSU KOSAN)
Table 4A1-1
Grease Names Makers
Alvania Grease No. 1 Showa Shell Sekiyu K.K
Multinoc Grease 1
Jomo Lisonix Grease No. 1
Dynamax No. 1 COSMO OIL LUBRICANTS
Lithtan 1 Exxon Mobil Corporation
MP Grease No. 1 KYGNUS
Gemico MP-1 Tonen General Sekiyu K.K
Multemp PS1 KYODOH YUSHI CO., LTD.
•
Grease Types equivalent to MOLYNOC GREASE AP1
Table 4A1-2
Grease Names Makers
DAPHINE Grease M No. 1 Idemitsu Kosan Co., Ltd.
Jomo Lisonix Grease M No. 1
COSMO MOLYBDEN GREASE
No. 1
COSMO OIL LUBRICANTS
BEACON Q2 Exxon Mobil Corporation
Gemico MD2 Tonen General Sekiyu K.K
M5 GREASE 1 KYGNUS
1.2 Preparation for Maintenance
4OM-1840
1-1-61604-001
Specied lubrication tools
(1) Brush
Notice
Do not use a brush for ball screws and splines.
(2) Vinyl Gloves
Use a pair of vinyl gloves to apply grease or oil by hand.
(3) Hand Grease Gun
Standard
: KH-120
Part No.
: KYB-M382J-00 (228A0022)
Maker
: Yamada Corporation
Note
Use this gun only for DAPHNE GREASE MP No. 1.
Reference
Refer to the attached instruction manuals for the hand grease gun for the
usage.
Fig. 4A1-4
•
Attachment for Hand Grease Gun KH-120
Table 4A1-3
Standard Shape Part No. Remarks
Type N
KYB-M382A-00
216M0440
THK
Type H
KYB-M3829-00
216M0439
THK
Type U
KYB-M3828-00
216M0438
THK
Type P
KYB-M3813-00
0920H11Q
THK
SPK-3C
KYB-M382H-00
228A0021
Yamada
Corporation
Note
It is not attached to the machine. Purchase it separately if necessary.
1.2 Preparation for Maintenance
4OM-1840
1-1-71604-001
(4) Syringe
Maker: TERUMO
This gun can be used for two types of greases.
Use the syringes and the nozzle properly.
Two Types of Greases : DAPHNE GREASE MP No. 1
MOLYNOC GREASE AP1
Appearance
Fig. 4A1-5
Table 4A1-4
Standard Shape Part No. Remarks
Syringe
KYB-M382K-00
228A0171
Maker : TERUMO
10ml SS-10-LZ
Nozzle No.18
(Color : Green)
---
216G0451
Maker : SAN-EI TECH
Inside Diameter :
f
0.84
Tapered Nozzle #5118TT-B
Nozzle No.19
(Color : Brown)
KYB-M380X-00
0916D108
Maker : NIPRO
Inside Diameter :
f
0.79
Length : 65 mm Flat End
1.2 Preparation for Maintenance
