1. Description of Recognition Error ID (Example) [1] [2] Recognition Error ID Description of Recognition Error 050**001 Component was not found. 051**001 Component was not detected. T4D1 [1] Recognition Error ID The reco…
4OM-1840
1604-001 4-B
1. Description of Recognition Error ID (Example)
[1]
[2]
Recognition Error ID Description of Recognition Error
050**001 Component was not found.
051**001 Component was not detected.
T4D1
[1] Recognition Error ID
The recognition error IDs (IDs displayed in the "ERROR" window) are
described in the numerical order.
[2] Description of Recognition Error
Described are the contents of a recognition error that will be displayed in the
"ERROR" window.
1. Description of Recognition Error ID (Example)
4OM-1840
4-1-11604-001
2. Recognition Error IDs and Controlled Areas
Basic System of Recognition Error IDs
An error ID is expressed by 8 digits (hexadecimal) as follows.
Z A B CC DDD
Detailed Classification
Small Classification
Middle Classification
Large Classification : Classification based on individual
recognition functions
Classification Criteria : Distinction between Recognition
System and Ordinary Errors
Classication Criteria
Classication Criteria Classication of Recognition Functions
0 Ordinary Errors
1 Recognition System Errors
T4D2
Large Classication
Classication Criteria Classication of Recognition Functions
0 Recognition Internal Errors
1 Recognition Communication Errors
2 Recognition Communication Errors
5 Component Recognition Errors
6 PEC Recognition Errors
7 Nozzle Recognition Errors
8 Character Recognition Errors
9 Bad Mark Detection Errors
a Recognition Teaching Errors (Reserved)
b
Component Library
Teaching Function Errors
c 2D Barcode Errors
d Support pin Detection Errors
f Vision System Start-up Errors
T4D3
2. Recognition Error IDs and Controlled Areas
4OM-1840
4-1-21604-001
