3.2 Data
Error ID Error Name, Description, Cause, and Remedy
410301 Pattern Program Error
Steps in converted pattern program is more
-----
410302 Pattern Program Error
There are Errors in converted pattern program(PCB recog steps Error.)
-----
410303 Pattern Program Error
The converted pattern program is not exist, the data is damaged.
-----
410304 Pattern Program Error
The error is found in the adsorption nozzle number of the conversion pattern
program.
-----
410305 Pattern Program Error
The error is found in the order of adsorption of the conversion system pattern
program.
-----
410306 Pattern Program Error
The error is found in the nozzle candidate number of the conversion pattern
program.
-----
410307 Pattern Program Error
The error is found in the adsorption lane number of the conversion pattern
program.
-----
410401 Data Error
The components library does not exist. Or, data is in loss.
-----
410402 Data Error
Data relating to nozzle does not exist. Or, data is in loss.
-----
410701 Program Error
It was a error setting of the sequence data.
-----
410801 2D bar code data Error
It was a error setting of the sequence data.
-----
410802 2D bar code data Error
Failed in start-up Sequence
-----
410803 2D bar code data Error
The error is found in coordinates calculation.
-----
3.2 Data
4OM-1840
3-3-191604-001
Error ID Error Name, Description, Cause, and Remedy
410804 2D bar code data Error
Could not continue for Errors.
-----
T4C4
3.2 Data
4OM-1840
3-3-201604-001
3.3 Conveyor
Error ID Error Name, Description, Cause, and Remedy
420001 Error in Transfer section
Transfer has errors.
-----
420002 Error in Transfer section
Transfer operation was not completed within a specied time.
-----
420003 Error in Transfer section
Positioning has errors.
-----
420004 Error in Transfer section
Input conveyor has errors.
-----
420005 Error in Transfer section
Positioning conveyor has errors.
-----
420006 Error in Transfer section
Output conveyor has errors.
-----
420007 Error in Transfer section
Interlock has been detected.
-----
420008 Error in Transfer section
Transfer was stopped.
-----
420101 Backup(L) Error.
The movement of Backup (L) Axis was not completed within predetermined time.
Backup axis is unable to do upward movement and downward movement.
The problem is for Motor, Driver, Sensor Error or wiring Error.
Please check the motor, sensor on Machine check screen.
420102 Backup(L) Error.
Driver Alarm on Backup (L) Axis
Check out reset Method of detailed Sub-system error counts of Alarm.
420103 Backup(L) Error.
Error in calculating data of Backup (L) Axis
Please check the following data
1. Machine Oset/Backup Pin(Up & Down)
2. Pattern program/P.C.B. information/P.C.B. size/thickness
3. Control/Common/PRE-PLACED CMPNT THKNS/Bottom of P.C.B.
420104 Backup(L) Error.
Time-over of zeroing of Backup (L) Axis
Check out the dirt, error, disconnection of sensor. If there is no problem with
sensor, the problem could be with motor wire/single error.
