SIPLACE 80S/F/G User’s Manual 5 Placement

Edition 12/96 from Software Version SR.009.xx 5.6 Error Menus

5 - 25

5.6 Error Menus

5.6.1 General

The error menus appear automatically on the screen after a fatal error. A fatal error means that the machine

cannot continue with placement without the intervention of the operator. When the error menus appears, you

are requested to press the start key in order to move the portal into the waiting position.

The menus "Track error 1" and "Track error 2" refer to the components table affected in each case. Since both

menus are identical, only the menu "Track error 1" will be described in this manual.

The menus "Machine error 1" and "Machine error 2" refer to the portal affected in each case. Since both

menus are also identical, here too only the menu "Machine error 1" will be described.

NOTE

As a standard procedure, only those functions are shown in the error menus which the operator can perform.

Only when the line engineer password has been entered is the full range of functions of the error menus

available.

All error menus can only be quit via the functions "Continue placement" or "Abort placement".

Following this error message you must select "Abort placement" once again if an operating error is to be

prevented.

WARNING

∆

The functions, which are only accessible after the line engineer password has been entered, may only be

implemented by appropriately qualified and trained personnel, since improper handling of them may result in

injuries and/or damage to the machine.

NOTE

In the menus Track error, Machine error and Nozzle change the protective cover is unlocked and the x and y

axes isolated. In these menus, the axes can only be moved when the protective cover has been closed.

If head functions are selected, the key-operated switch will have to be turned with the cover open in order to

allow head functions to be used (for example, cycle star).

If the key-operated switch is activated when the protective cover is closed, the axes will be able to travel only

at the lower speed.

5 Placement SIPLACE 80S/F/G User’s Manual

5.6 Error Menus Edition 12/96 from Software Version SR.009.xx

5 - 26

5.6.2 Transport Error Menu

The transport error menu appears on the screen when errors occur while the printed circuit board is being

transported. Possible errors include for example: the ultrasound sensors do not respond correctly, or the

printed circuit board is not stopped or clamped.

5.6.2.1 Range of Functions for the Operator

Fig. 5.6.1

PCB to output conveyor

When the function "PCB to output conveyor" is selected via the cursor keys and the

Return key

, a printed

circuit board on the center conveyor is conveyed onto the output conveyor and left there for removal by

hand. Components already picked up remain at the placement head.

PCB to center conveyor

When the function "PCB to center conveyor" is selected via the cursor keys and the

Return key

, a printed

circuit board on the input conveyor is transported onto the center conveyor, stopped and clamped.

Display errors

To obtain a display of all errors which have occurred, use the

cursor keys

to select the menu point "Display

errors". Then press the

Return key

. On the screen the menu "Display errors" described in Section 5.7 (Dis-

play functions) will appear.

SI 80 V 9.x

Nutzen:

Rüstung :

Error

State

Action

Transport error

Abort placement

Display errors

PCB to center conveyor

PCB to output conveyor

Error treatment - transport errors

Continue placement

SIPLACE 80S/F/G User’s Manual 5 Placement

Edition 12/96 from Software Version SR.009.xx 5.6 Error Menus

5 - 27

Abort placement

Use the

cursor keys

to select the menu item "Abort placement" in order to quit the error menu without

placement continuing, and press the

Return key

. The board on the conveyor is transported to the output

conveyor and the component at the placement head ejected. The portals are moved into the waiting posi-

tion.

Continue placement

Use the

cursor keys

to select the menu item "Continue placement" in order to continue placement. Then

press the

Return key

. The machine transfers the printed circuit board which is on the conveyor and asks

the operator to insert a new board. In order to continue placement the machine requires a board in the

placement zone.

5.6.2.2 Range of Functions for the Line Engineer

After the line engineer password has been entered, the following additional functions are shown in the trans-

port error menu:

Sensor state

Use the

cursor keys

to select the menu item "Sensor state" in order to display the current state of the ultra-

sound sensors. Then press the

Return key

. In the righthand area of the "Transport error" menu the current

state of the ultrasound sensors (responded 1, not responded 0) is displayed.

Transport status

The menu item "Transport status” shows how the statuses (1/0) of the board conveyor have been set in the

software.

Use the

cursor keys

to select the "Transport status" menu in order to display the current states of the board

conveyor, and press the

Return key

. In the righthand area of the "Transport error" menu the current state of

all board conveyor functions is shown.

Actuate clamping

After selecting the function "Actuate clamping" by means of the

cursor keys

and pressing the

Return key

clamping is activated (any printed circuit board which is on the conveyor is clamped in position). When the

Return key

is pressed again the clamping device returns to the home position. This procedure can be

repeated as often as desired by pressing the

Return key

Actuate stopper

After selecting the function "Actuate stopper" using the

cursor keys

and pressing the

Return key

, the stop-

per is extended. When the

Return key

is pressed again the stopper returns to its home position. This

sequence can be repeated by repeatedly pressing

Return key

Cycle mode

Use the

cursor keys

to position the cursor bar over the menu item "Cycle mode". Then press the Return

key. For each step of the placement sequence you will now need to press the start button.
