7 Vision Systems SIPLACE 80S /F/G User’s Manual 7.6 Test Component Edition 07/97 f rom Software Version SR.010.xx 7 - 70 Line engine er 7.6.3.3 Option “Display component ” NOTE Before y ou activate th is option , a compo…
SIPLACE 80S/F/G User’s Manual 7 Vision Systems
Edition 07/97 from Software Version SR.010.xx 7.6 Test Component
Line engineer 7 - 69
7.6.3.2 Option “Pick up component”
NOTE
Before you can activate this option, you must have already entered a GF number. If this is not the case, a mes-
sage is displayed asking you to enter a GF number.
Fig. 7.6.6
When this option is activated the following actions are initiated:
–
A component will be picked up from a specific track.
–
If a component is already under the component camera, it will be ejected.
Error
State
Action
Pickup component
Single functions
:
:
:
SI80 V 10.x
Vision system
Vision system
BE - Zuführung
Vision system
Version: 2133
Test component
Enter GF number
Pickup component
Display component
Measure component
Test component
Edit GF data
Change measure mode
Refill
Display errors
Test output
First enter GF number, please.
Press space bar
War ning
7 Vision Systems SIPLACE 80S/F/G User’s Manual
7.6 Test Component Edition 07/97 from Software Version SR.010.xx
7 - 70 Line engineer
7.6.3.3 Option “Display component”
NOTE
Before you activate this option, a component must already be under the component camera. In addition, a GF
number must already have been entered.
Fig. 7.6.7
When this option is activated the following actions are initiated:
–
The teach command is initiated.
–
The vision system generates the external contours of the component from the synthetic description
–
The video image with the real camera image and the model superimposed on it is displayed on the screen.
–
The top line with comments is also displayed.
Error
State
Action
Enter package form number
Rüstung:
Single functions
:
:
:
BE - Zuführung
SI80 V 10.x
Vision system
Vision system
Vision system
Version: 2133
Test component
Enter GF number
Pickup component
Display component
Measure component
Test component
Edit GF data
Change measure mode
Refill
Display errors
Test output
SIPLACE 80S/F/G User’s Manual 7 Vision Systems
Edition 07/97 from Software Version SR.010.xx 7.6 Test Component
Line engineer 7 - 71
The operator can now visually check the synthetic description for agreement with the real image.
Fig. 7.6.8
With “ESC” you can terminate the function. The video image disappears and the menu “Test component” is
displayed once again.
GF No. = 5Display component
