5 Placement S IPLACE 80S/F/G User’s Manual 5.4 Component Handling Ed ition 12/96 from Software Version SR.009.xx 5 - 12 NOTE If refill c heck has be en set in the machine options, onl y then will i t be possib le to refi…

SIPLACE 80S/F/G User’s Manual 5 Placement

Edition 12/96 from Software Version SR.009.xx 5.4 Component Handling

5 - 11

5.4 Component Handling

All inputs which are connected with components supply are listed in the menu "Component feeding". When a

cluster is started for the first time, the machine assumes that all tracks have been filled with components. If,

after three pick-up errors, the track is regarded by the machine as empty, the track should be set full, once it

has been charged with components.

5.4.1 Component Barcode (Option)

The SIPLACE 80 S placement machine includes an option for checking track assignment for agreement using

a barcode reader.

For this purpose, black plates with four-position barcode strips are fitted to the safety side panels. The first

position identifies the components table (1 or 2), while the remaining three positions give the track number.

Each end of the plate includes

return barcodes

, which have the same function as the

Return key

on the key-

board.

These barcode strips are continuously numbered in steps of two (1, 3, 5, 7......), and apply to 2 tracks in each

case (barcode 1 = tracks 1 and 2).

The barcodes are read in using a pen reader connected to the keyboard.

NOTE

When reading in the barcode do not hold the barcode pen vertical, but at a slight angle to the barcode.

NOTE

If the barcode option is not installed, all inputs have to be made using the keyboard.

NOTE

Barcodes which begin with the numeral 1 or 2 and have a length of 4 characters are interpreted as track

barcodes. All other barcodes, that is, those which do not begin with a numeral, are interpreted as component

barcodes.

5 Placement SIPLACE 80S/F/G User’s Manual

5.4 Component Handling Edition 12/96 from Software Version SR.009.xx

5 - 12

NOTE

If refill check has been set in the machine options, only then will it be possible to refill and reset using bar-

codes.

If refill check has not been set in the machine options, it is possible to choose whether to use the barcode

function. It is however still possible to perform a manual reset.

5.4.2 Menu "Component Feeding"

●

In the main menu use the

cursor keys

to select the menu item "Component feeding" . The menu "Compo-

nent feeding" is displayed on the screen.

●

Press the

Esc key

to return to the main menu.

●

If you wish to make any inputs (eg setting tracks to full), use the

cursor keys

to select a menu item and

press the

Return key

Fig. 5.4.1

5.4.3 Function "Fill all"

After entering the

line engineer password

the function "Fill all" is shown in the menu "Component feeding".

After selecting this function using the

cursor keys

and calling using the

Return key

, all empty tracks are set to

full and the relevant track errors cancelled. To enable this function to be performed, the refill test in the

machine options menu must be disabled (see Section 5.3.1).

SI 80 V 9.x

Cluster:

BE - Zuführung

Neuer Nutzen

Display errors

Confirm errors

Machine options Single functions

Error

State

Action

Softwareoptionen

Masch.Fehler anz.

Spurfehler anz.

Refill

Location 1

Location 2

Location 3

Location 4

Component feeding

Fill all

Fill empty tracks separately and continue

SIPLACE 80S/F/G User’s Manual 5 Placement

Edition 12/96 from Software Version SR.009.xx 5.4 Component Handling

5 - 13

5.4.4 Menu "Refill"

If you have selected the menu item "Refill" in the menu "Component feeding", the "Refill" menu appears on the

screen.

In this menu all inputs connected with track assignment are carried out. You can use the barcode reader

(option) or the keyboard to make the inputs.

Key Functions:

Esc key:

This key is used to return to the "Component feeding" menu.

Return key:

With this key the inputs are taken over and the track which has been checked

(it is highlighted by a yellow background) is set to full. Tracks which have not been

checked are set to empty.

Spacebar:

Using this key a line can be selected in the righthand window of the refill menu.

Tab key:

Using this key you can move between the two windows.

Cursor keys:

Using these keys the cursor bar can be moved within the selected window.

Fig. 5.4.2

1. BC + filter:

4. BC + filter:

2. BC + filter:

3. BC + filter:

5. BC + filter:

6. BC + filter:

12 1 0

CO-R12534 *

33 1 0

CO-R12534 -

69 1 0

CO-R12534 *

48 1 0

CO-R12534 -

2007

TRX-7

TRY-3

Y-7

B-7

TRX-8

TRA-7

Error

State

Action

Fill empty tracks separately and continue

ESC: abort Ret. input Blank: select Tab: change wind

Track barcode:

Comp barcode:

Refill

Level Comp nameDivTrackLoc
