5 Placement SIPLACE 80S /F/G User’s Manual 5.6 Error Menus Edition 12/96 from Software Version S R.009.xx 5 - 42
SIPLACE 80S/F/G User’s Manual 5 Placement
Edition 12/96 from Software Version SR.009.xx 5.6 Error Menus
5 - 41
Fig. 5.6.9
●
With the space bar select cycle mode on (X) or cycle mode off ( ) and confirm this selection with the return
key.
●
For every step of the placement sequence you must now press the start button. The abort menu remains
displayed on the screen.
●
With the aid of the cursor keys position the cursor bar over the menu item "Continue placement". After
doing so, press the return key.
The placement machine then continues with placement in the cycle mode once the start button has been
pressed.
SI 80 V 9.x
Display errors
Confirm errors
Machine options
Error
State
Action
:
:
:
Rüstung :
Abort menu
Continue placement
Best. abbrechen
Esc: abort Ret: input Blank: select
( ) Cycle mode
Cycle mode
5 Placement SIPLACE 80S/F/G User’s Manual
5.6 Error Menus Edition 12/96 from Software Version SR.009.xx
5 - 42
SIPLACE 80S/F/G User’s Manual 5 Placement
Edition 12/96 from Software Version SR.009.xx 5.7 Display Functions
5 - 43
5.7 Display Functions
5.7.1 Display Errors
In the menu "Display errors" various classes of errors can be called up and displayed.
In the main menu use the cursor keys to select the menu item "Display errors". Next press the
Return key
. The
screen then displays the menu "Display errors".
Fig. 5.7.1
5.7.1.1 Machine Error Display
The menu "Machine errors" can be called up from both the menu "Display errors" as well as from various error
menus.
In the menu "Display errors" select the menu item "Machine errors" or in the active error menu use the cursor
keys to select the menu item "Machine errors". Next press the
return key
. The menu "Machine errors" will be
displayed on the screen.
SI 80 V 9.x
Cluster:
Component feeding
Confirm errors
Machine options
Error
State
Action
:
:
:
Display errors
Rüstung :
Display errors
Track errors
Machine errors
Transport errors
General errors
