2 Operational safety 2.1 Safety instructions User Manual / Bedienungsanleitung / 用户手册 SIPLACE TX V1/V2 Series JEDEC Tray Feeder (JTF-ML2) 11/2019 109 2.1.6 Safety Instructions for Transporting the Module Fig.9: Holding …
2 Operational safety
2.1 Safety instructions
108 User Manual / Bedienungsanleitung / 用户手册 SIPLACE TX V1/V2 Series JEDEC Tray Feeder (JTF-ML2) 11/2019
Areas of the SIPLACE JTF-ML2 at which there is a danger of crushing
Fig.4: Do not reach into the JTF or into the machine
through the JTF
Fig.5: Moving magazine
Fig.6: Conveyor belt rollers
Fig.7: Sliders
Fig.8: Side tray clamp
2.1.5 Risk of crashing when using thick JEDEC trays
DANGER
Risk of crashing when using thick JEDEC trays
►
Do not use thick JEDEC trays in combination with C&P20P2 or CPP_L.
Otherwise, the head will be damaged.
See also
2 3.2 "Overview – SIPLACE JTF-ML2" [}119]
2 Operational safety
2.1 Safety instructions
User Manual / Bedienungsanleitung / 用户手册 SIPLACE TX V1/V2 Series JEDEC Tray Feeder (JTF-ML2) 11/2019 109
2.1.6 Safety Instructions for Transporting the Module
Fig.9: Holding the tower
CAUTION!
Tower weight
The weight of the tower (26.3 kg) could
cause injuries if the module is not
handled correctly.
Always hold the tower with two hands.
Use the handles on the sides of the
tower.
Tower and conveyor must be transpor-
ted separately. Mishandling will cause
damage to the SIPLACE JTF‑ML2.
.
2 Operational safety
2.2 Warning labels
110 User Manual / Bedienungsanleitung / 用户手册 SIPLACE TX V1/V2 Series JEDEC Tray Feeder (JTF-ML2) 11/2019
2.2 Warning labels
The warning labels are made from soft PVC film, and are abrasion-proof, light-fast and resistant to
water and weathering.
2.2.1 Warning Labels on the SIPLACE JTF-ML2
Fig.10: Warning Labels on the SIPLACE JTF-ML2
1) GB 2894 Warning Label 202
The SIPLACE JTF-ML2 has a GB 2894
warning label202.
See 2.2.3 "GB 2894 Warning Label
202" [}111].
WARNING!
Danger to life from powerful mag-
netic fields inside the machine!
Forbidden for persons with pace-
makers, implants and magnetic items
on the body
.
2) Warning Strips
The SIPLACE JTF-ML2 has a warning strip.
WARNING!
Danger of Crushing
Reaching in here can lead to injuries to
the arms and hands.
Do NOT reach through the module into
the machine while the machine is run-
ning.
.
3) Warning Label W204
The SIPLACE JTF-ML2 has two warning
labelsW204.
See 2.2.4 "Warning label W204" [}111].
WARNING!
Danger of Crushing
Reaching in here can lead to injuries to
the arms and hands.
Do not reach into the module while it is
running.
.
2.2.2 Warning, Prohibition and Cautionary Labels
WARNING
Damage to warning labels
Incorrect cleaning can damage the warning labels.
ü Using the correct cleaning agents.
► Do not use abrasive cleaners or solvents for cleaning warning labels.
► Replace any damaged or illegible warning labels.
► Verify that the warning labels are positioned correctly.
