3 Technical data of the module
3.2 Overview – SIPLACE JTF-ML2
User Manual / Bedienungsanleitung / 用户手册 SIPLACE TX V1/V2 Series JEDEC Tray Feeder (JTF-ML2) 11/2019 119
3.2 Overview – SIPLACE JTF-ML2
Fig.20: SIPLACE JTF-ML2
SIPLACE JTF ML2 (Tray Feeder Module)
[00588116‑xx]
A)Tower
B)Conveyor
C)SIPLACE JTF‑ML2 adapter
1. Door
2. Handles
3. Pick position
Fig.21: Cassette for 9 trays (standard)
SIPLACE JTF-ML2 Tray Cassette 9
[00588199-xx]
The SIPLACE JTF-ML2 is delivered with two
cassettes for 9 trays as standard.
This cassette type can only house thin
JEDEC trays.
1. Shipping brace
2. Security spring
3. Handles
4. Guides for JEDEC trays
5. Direction lock
3 Technical data of the module
3.2 Overview – SIPLACE JTF-ML2
120 User Manual / Bedienungsanleitung / 用户手册 SIPLACE TX V1/V2 Series JEDEC Tray Feeder (JTF-ML2) 11/2019
Fig.22: Cassette for 7 trays (optional)
SIPLACE JTF-ML2 Tray Cassette 7
[00588177-xx]
Cassettes for 7 trays can be ordered separ-
ately.
This cassette type can house thin (7.62mm)
and thick (12.19mm) JEDEC trays.
1. Transportation locks (2x)
2. Security spring
3. Handles
4. Guides for JEDEC trays
DANGER
Risk of crashing when using thick JEDEC trays
►
Do not use thick JEDEC trays in combination with C&P20P2 or CPP_L.
Otherwise, the head will be damaged.
4 Setting up and commissioning
4.1 Requirements and restrictions
User Manual / Bedienungsanleitung / 用户手册 SIPLACE TX V1/V2 Series JEDEC Tray Feeder (JTF-ML2) 11/2019 121
4 Setting up and commissioning
NOTICE
Example shown as diagram
The following diagrams are just examples. The procedure is the same for other machine
types than the SIPLACE TX1 / TX2-V1 / V2 shown. Any relevant differences will be men-
tioned explicitly.
4.1 Requirements and restrictions
The following requirements and restrictions apply to the SIPLACE JTF-ML2:
●
Assembly is only possible on SIPLACE TX1 and TX2 machines.
Assembly is not possible on SIPLACE TX2i machines.
●
The software version of a SIPLACE TX1/TX2 V1 machine must be 710.1 or higher. The soft-
ware version of a SIPLACE TX1/TX2 V2 machine must be 711.1 or higher.
●
The assembly is only possible at location 1.
●
The conveyor and the tower of the SIPLACE JTF-ML2 have the same ID number and must al-
ways be working as a pair.
It is not allowed to use a conveyor and a tower with different ID numbers.
Placement Heads
The following placement heads are possible:
●
CPP_H
●
TwinHead
From SIPLACE TX V2:
●
C&P20 P2
●
CPP_L
●
CPP M
Information on additional placement head variants are available upon request.
Also observe: 2.1.5 "Risk of crashing when using thick JEDEC trays" [}108]
Trays
NOTICE
Magnets with reduced height for Cookie Trays
When using magazine sheets (Cookie Trays), magnets with reduced height are required
[03160331‑xx]. For details, refer to the Technical Information "Magnet for JTF-ML2 Cookie
Tray" [DE:TI2019‑06D01] [EN:TI2019‑06E01].
