From the Features list in the left window, you can select the application features you want to
add to the application to be generated. To select a feature, mark the check box next to the
feature name.
If you want an e-mail to be sent to certain users, if the pickup error rate during production
exceeds a set value, enable the Alarm feature.
Users can be defined with the User Management feature of the Factory Configuration Utility.
The alarms can be set with Step 6 of Line Configuration. For further information, please see
“Step 6 - Modify Application Parameters” on page 45. 3
Enable the function Production Files, to activate Backflush.
Check the features for the relevant machines of all available production lines and add other
features, where necessary.
Repeat all steps separately for each production line.
After selecting all the features for the machines and production lines, click Next to continue
with the next step.
3.6.1.5 Step 4 - Set Up Production Line Schedule
The SIPLACE Explorer Calendar allows you to specify a production line schedule: 3
– Define a weekly shift schedule,
– Plan maintenance and scheduled downtime for machines in the production line.
– Apply the schedule to a time interval.
Getting Started SIPLACE Explorer 3 SIPLACE Explorer Runtime Environment
from 3.11 (R20-2) Edition 11/2020 EN
37
3
Fig. 3 - 18 Step 4: Set production line schedule
When the schedule for the production line as been defined, click on Next to continue with the
next step.
3 SIPLACE Explorer Runtime Environment Getting Started SIPLACE Explorer
Edition 11/2020 EN from 3.11 (R20-2)
38
3.6.1.6 Step 5 - Configure System Database
Now, you can configure the SIPLACE Explorer System database settings:
– Microsoft SQL Server instance:port number
You can add the port number to the SQL Server instance, separated by a colon, for
example: PLK0495A\SIPLACE_2005EXPR:12345.
– Database name
– User Name
– Password
f you have imported a production line from the OIS the SIPLACE Explorer database settings
are automatically adopted.
NOTE
Click on the Browse for SQL instances icon. All SQL server instances available will be
shown in the Select SQL Server instance dialog box.
If the Select SQL Server instance dialog box shows no entries, you need to specify the SQL
server instance manually in the MS SQL Server field. 3
