Getting Started SIPLACE Explorer 3 SIPLACE Explorer Runtime Environment
from 3.11 (R20-2) Edition 11/2020 EN
47
Day-Based Output enabled
– Column Value, entry true:
The component consumption per day is recorded and an xml file is generated every day,
for each line.
– Column Value, entry false:
No data recording.
NOTE
The factory/shift calendar indicates when a production day begins or ends. This
information can be defined in the Factory Configuration Utility. 3
Day-Based Output directory
Enter the target folder for the generated xml file, here. 3
Recipe Output Enabled
– Column Value, entry true:
The downloaded recipe is recorded and an xml file is generated for each downloaded
recipe.
– Column Value, entry false:
No data recording.
Recipe Output Directory
Enter the target folder for the generated xml file, here.
Station-E10 Output Enabled
– Column Value, entry true:
The E10 state transitions are recorded and an xml file is generated for each time inter-
val. The default setting is a time interval of 5 minutes.
– Column Value, entry false:
No data recording.
Station-E10 Output Directory
Enter the target folder for the generated xml file, here.
Station-E10 Output Interval (min)
Specify a time interval in minutes, for the recording period. You can enter a value from 1 ..
1440 minutes (24 hours). Data recording and xml file generation will be started after website
generation. The default setting is a time interval of 5 minutes. 3
3 SIPLACE Explorer Runtime Environment Getting Started SIPLACE Explorer
Edition 11/2020 EN from 3.11 (R20-2)
48
Warning Mailing List
Shows a list of those users who will receive a warning per e-mail, if the system is unable to
generate the consumption data in the specified target folder. You need to define these users
in the Factory Configuration Utility. 3
NOTE
For a detailed description of the generated xml files, please refer to Annex on page 99. 3
Once you have made all modifications, click on Next to continue with the next step.
3.6.1.8 Step 7: Website Generation
In order to monitor your production line in the web browser, you will need to generate a website.
For this purpose, you require web server manager privileges (Tomcat website creator,
deployer) and the corresponding password. If you have imported a production line from the
OIS the webserver access data are automatically adopted.
3
Fig. 3 - 29 Step 7: website generation
At Website Generation, specify whether and when the website is to be generated. The
following options are available:
Getting Started SIPLACE Explorer 3 SIPLACE Explorer Runtime Environment
from 3.11 (R20-2) Edition 11/2020 EN
49
– Generate line website
The website will always be generated for the selected production line.
– If changes to line settings were made
A website will only be generated if changes have been made to the production line
configuration.
– Do not generate line website
Website generation will not be performed. This can be performed later, while editing the
generated application.
Specify the access data for the Tomcat website generator. If you entered admin and an empty
password during Tomcat configuration, this data will be automatically used as a default login.
If this is not the case, use the data you specified during Tomcat configuration. If you have
imported a production line from the OIS the webserver access data are automatically adopted.
