– Step 2 - Perform Configuration Test
At Step 2 you can change your settings. This is also where you define the name of the SE
system database for the line and where you specify the user (and password) who is to have
access to this database.
3
Fig. 3 - 35 Step 2 - database connection wizard
Once you have made and checked all entries, click on Next to continue.
Getting Started SIPLACE Explorer 3 SIPLACE Explorer Runtime Environment
from 3.11 (R20-2) Edition 11/2020 EN
57
– Step 3 - Configure Database
Step 3 takes your modifications from Step 2 and uses them to configure the database
connection.
3
Fig. 3 - 36 Step 3 - database connection wizard
Click on Finish and the wizard will carry out the required configuration. The DB settings are
now correctly specified for your project. The database and set user will be created.
You will receive a success message.
3
Fig. 3 - 37 Step 3 - database connection wizard
Click OK. You can now configure your system database.
3 SIPLACE Explorer Runtime Environment Getting Started SIPLACE Explorer
Edition 11/2020 EN from 3.11 (R20-2)
58
3.7.2 Converting the Database
Due to the changed data structure in the SIPLACE Explorer 3.11 database, existing databases
with data from SIPLACE Explorer 2.0 - 3.10 need to be converted. 3
Always perform the conversion when you need to access a database which does not yet have the
SIPLACE Explorer 3.11 database format. This could occur in the following cases: 3
– Using the SE database
– Runtime Environment:
Step 5 - Configure System Database page 38
– Development Environment:
Step 7 - Configure System Database page 38
– Using the factory database
– Factory Configuration Utility
Loading the DB settings on Factory Configuration Utility start, page 78
Database conversion can only be performed if a connection has already been established to the
database. 3
The Convert database dialog box will open.
NOTE
Consider the following for database conversion:
- You will need database administrator rights.
- If you have started the conversion, this process can not be stopped.
- The conversion time depends on the size of the database and on the performance of the
computer. It may take up to an hour. 3
