4 SIPLACE Explorer Factory Configuratio n Utility Getting Started SIPLACE Explorer Edition 11/2020 EN from 3.11 (R20-2) 96 4 Fig. 4 - 23 Factory configur ation utility - restore defaults in 4.8.1.4 Generate W ebsite ... …
Getting Started SIPLACE Explorer 4 SIPLACE Explorer Factory Configuration Utility
from 3.11 (R20-2) Edition 11/2020 EN
95
4.8.1.1 Load Settings from ...
This is where you can select the required factory settings from a list of available factory settings.4
In the File menu, select the item Load Settings from ....
4
Fig. 4 - 22 Factory configuration utility - load settings from
4.8.1.2 Save Settings
This is where the factory settings just defined can be saved. 4
In the File menu, select the item Save Settings.
4.8.1.3 Restore Defaults
This is where the default settings set on delivery can be restored. 4
CAUTION
This deletes all entries for this factory database 4
In the File menu, select the item Restore defaults.
Exit Terminates the Factory Configuration Utility.
Function Action
4 SIPLACE Explorer Factory Configuration Utility Getting Started SIPLACE Explorer
Edition 11/2020 EN from 3.11 (R20-2)
96
4
Fig. 4 - 23 Factory configuration utility - restore defaults in
4.8.1.4 Generate Website ...
This is where you can generate a website on which to view a summary of the factory settings. For
this purpose, you require web server manager privileges (Tomcat website generator, deployer)
and the corresponding password. 4
Select Generate Website ... from the File menu.
4
Fig. 4 - 24 Factory configuration utility - generate website
Specify the access data for the Tomcat website generator. If you entered admin and an empty
password during Tomcat configuration, this data will be automatically used as a default login.
If this is not the case, use the data you specified during Tomcat configuration.
Enter the following information:
– URL site
This URL contains a port number, which applies to the web server (Tomcat) e.g. "8080". If
you change the port number here, you will also need to update the port number of the web
server. For a detailed description, please see the installation instructions.
– Refresh rate
For capacity purposes, we recommend a refresh rate of at least one minute (60000 ms).
– Factory website language
Check your entries and confirm with OK. Factory website generation will begin. For a detailed
description of the factory website, please refer to SIPLACE Explorer SMA User Guide.
Getting Started SIPLACE Explorer 4 SIPLACE Explorer Factory Configuration Utility
from 3.11 (R20-2) Edition 11/2020 EN
97
4.8.1.5 Websites Clean-up Options
This is where you can define the properties of the clean-up options for line websites and factory
websites. 4
Select Websites clean-up ... from the File menu.
4
Fig. 4 - 25 Factory configuration utility - websites clean-up
Enable the necessary options.
Check your entries and confirm with OK.
4.8.1.6 Language
The language for the Factory Configuration Utility can be set here. 4
In the File menu, select Language...
4
Fig. 4 - 26 Factory configuration utility - select language
Select the required language and confirm your choice with OK.
4.8.2 Menu Scheduler
To generate the configured factory reports, start the scheduler here. You have already defined the
generation of the factory reports in the Reports tab, see ”Reports”, page - 85. When started, the
scheduler automatically creates a scheduled task. This scheduled task instructs the system to
read factory report data out of the line databases and to create factory reports in the form of Excel
files. 4
In the Scheduler menu, select Start Scheduler... or click on the Start Scheduler icon.
Generation of the specified report will begin. The Start Scheduler icon in the toolbar will
change to Stop Scheduler .
