Instruction manual SIPLACE CA4 V2 2 Operational safety
From software version 713.0 Edition 12/2019 2.1 Safety instructions
29
If particularly hazardous situations are identified while the placement machine is in use, the
placement machine operating company must immediately notify the manufacturer in writing
so that appropriate action can be taken to reduce the potential danger.
2
2.1.3.2 Safety of operators and other persons
Placement machine operators must only carry out work for which they have been adequately
trained and with which they are totally familiar.
NEVER open one of the protective covers if you are not totally familiar with the use and func-
tioning of the placement machine! Do not open the protective covers during operation unless
you are told to do so in this manual or in the station software dialog.
The placement machine may only be operated if there is a component trolley and/or SIPLACE
Wafer System (SWS) present and docked at each location.
For your own safety, wear work clothes that conform to the guidelines of the professional as-
sociation or to the regulations of your country, i.e. safety shoes, hair net or no wide sleeves
etc.
Reduce the risks by not wearing scarves, chains or ties at your work post.
People with long hair must wear a protective head covering.
The placement machine may not be splashed with water or come into contact with other flu-
ids. Cleaning with wet cloths is also not permitted.
In the event of malfunction, high temperatures could arise on the housing of the relevant mo-
tor.
The Z axis of the placement heads is also live with 42 V when the protective cover is open.
For this reason, avoid any work to the Z axis (e.g. manual changing of nozzles). There is a
risk of injuries being caused.
Always wear protective clothing when handling the temperature-controlled vacuum tooling.
See also section 2.2.4
, page 42.
WARNING
Severe injuries and damage to equipment in the case of incorrect usage!
In the event of the placement machine being incorrectly used, movement of the gantries
or lifting tables, for example, could lead to severe injuries and considerable damage to
equipment.
Safe operation of the placement machine requires correct usage by qualified staff with
observance of all warnings.
Some work on the placement machine (e.g. setting up) requires training that goes be-
yond the scope of this manual.
2 Operational safety Instruction manual SIPLACE CA4 V2
2.1 Safety instructions From software version 713.0 Edition 12/2019
30
2
2.1.3.3 Safety of plant and equipment
Never make changes, however minor, unless you are totally aware of the effect they will have
on the overall functioning of the system.
The stations must always be set up, retooled and maintained by appropriately trained person-
nel.
Do not make modifications to the safety equipment. In particular, NEVER deactivate position
switches or remove safety devices.
If temperature-controlled vacuum tooling is present in the SIPLACE CA4 V2, you must wear
the prescribed protective clothing (see also section 2.2.4
, page 42).
2.1.4 Safety instructions for laser units
Permission to operate components that are classified as lasers is withdrawn if
– Mechanical damage to the unit is observed, or
– Any work is done on the mechanical or electrical parts of the unit. Even damaged or miss-
ing screw locking paint on laser components (e.g. cover plates, fasteners, adjusting po-
tentiometer) counts as work.
– Only ASM Assembly Systems GmbH&Co.KG service engineers or the machine owner's
service engineers, who have been trained by ASM, may replace laser components.
– Repairs to laser assemblies may only be performed by ASM Assembly Systems
GmbH&Co.KG at their factory.
WARNING
Dangerous voltage levels!
The placement machines are operated electrically. Certain parts are still live when the
main power switch is off and the mains plug has been disconnected. Switch off the main
switch, secure to prevent switching on, disconnect the mains plug and wait for 5 minutes.
There is a risk of death, severe injury and/or considerable damage to equipment if these
instructions are not followed.
Switch off at the main switch and disconnect the placement machine from the power
supply before carrying out any work on live components.
Check that there is no voltage present. See the procedure described in the service
manual.
Lock the placement machine as described in section 2.9, page 89.
Instruction manual SIPLACE CA4 V2 2 Operational safety
From software version 713.0 Edition 12/2019 2.1 Safety instructions
31
2.1.5 Safety instructions on permanent magnets
Powerful permanent magnets are used for the linear motors of the X and Y axes.
2
2
2
DANGER
Risk to life from powerful magnetic fields caused by the permanent magnets inside the
placement machine
When protective covers are opened inside the placement machine, the life of persons
with the following passive or active implants is put at risk:
– Pacemakers
– Defibrillators
– Insulin pumps etc.
At-risk people may not stand in the immediate vicinity of the placement machine.
WARNING
DANGER OF CRUSHING!
There is a danger of crushing for persons with passive metal implants (e.g. plates,
screws).
Never reach into the placement machine when the protective covers are open and
do not bend over the open placement machine.
Do not bring any metal objects into the danger area.
CAUTION
Data loss due to powerful magnetic fields!
There is a risk that the powerful magnetic fields could corrupt data on data media or credit
cards and check cards.
Keep data carriers and check cards away from the placement machine.
