4 Functions Overview SMA Guide SIPLACE Explorer Edition 11/2020 EN from 3.11 (R20-2) 74 4 Fig. 4 - 21 T opic: 7_X4_3 - performance daily The following machine information will be provided: 4 – Daily performance –T i m e …

SMA Guide SIPLACE Explorer 4 Functions Overview

from 3.11 (R20-2) Edition 11/2020 EN

– Total Processing

The Sum of all Processing Time and Move/Wait Times for the equipment. 4

ProcessT_total = (Wait_MoveT + ProcessT(ZoneN) + ProcessT(ZoneN+1) ...) 4

– Bar Chart Segments

Holding the mouse over a segment of the bar chart will display in a tool tip the value of the

segment. 4

– Scaling Zoom In/Out

By clicking and dragging - it is possible to zoom the scale of the bar chart for viewing of smaller

values. This is especially useful if a large value is displayed elsewhere on the chart and you

wish to view a smaller value. Double clicking near the top of the chart will return the Zoom

Factor to the original. 4

The following procedures can be performed on this page and are described in this SMA

User Guide:

 “How to Sort Tables” on page 96

 “How to Enable Legends” on page 96

4.2.2.3 Performance Daily

The function of this page is similar to the "Line Performance" diagram providing key data for the

specific machine for the selected evaluation interval, on a daily basis. From this view, weekly or

monthly reports (By Day) can also be provided, according to the evaluation interval setting. 4

NOTE

The data provided on this page is MaDaMas data and does not show the E10 status module. Use

the displayed information to compare a Line Computer Unix production line with a SIPLACE

Explorer production line. 4

4 Functions Overview SMA Guide SIPLACE Explorer

Edition 11/2020 EN from 3.11 (R20-2)

Fig. 4 - 21 Topic: 7_X4_3 - performance daily

The following machine information will be provided: 4

– Daily performance

–Time

– Number of processed boards per day

Explanation of Table: 4

For each day within the evaluation interval: 4

– Bar chart:

For each operational State of a station (Running, Waiting, Blocked, Interrupted, Failed, Other,

Unknown) a colored bar is displayed indicating the percentage of time allocated for each Share

of Time for the Target Date. 4

– Running Time:

Sum of time for the target date in Running Share of Time. 4

– Waiting time:

Sum of time for the target date in Waiting Share of Time. 4

– Blocked Time:

Sum of time for the target date in Blocked Share of Time. 4

SMA Guide SIPLACE Explorer 4 Functions Overview

from 3.11 (R20-2) Edition 11/2020 EN

– Interrupted Time:

Sum of time for the target date in Interrupted Share of Time. 4

– Fault Time:

Sum of time for the target date in Fault Share of Time. 4

– Other Time:

Sum of time for the target date in Scheduled Downtime, Non-Scheduled Time. 4

– Unknown Time:

Sum of time for the target date in Unknown - system has been powered off or is disconnected. 4

– Total Time:

The duration of the interval currently under evaluation by day. The sum of the "Shares of Time",

"Unknown" and "Other" time. 4

– PCB Count [pieces]:

Number of PCBs that have passed through the station during the day. It is possible that more

than one recipe is involved for the duration under evaluation. 4

– Component Summary [pieces]:

Number of components that have been consumed by the Placement station during the day. If

the machine is other than a placement system a Zero (0) value is displayed (See Definition of

Component Sum - Line Performance). 4

– Placed Component Summary:

Total number of components that have been consumed by the Placement station during the

day. 4

– Wasted:

Number of components that have not been used by the Placement station during the day. 4

– Pickup Errors [%] / [Count]:

Number of pickup errors that have occurred on the station during the evaluation interval. 4

– Ident Errors [%] / [Count]:

Number of identity errors that have occurred on the station during the evaluation interval. If the

machine is other than a placement system a Zero (0) value is displayed (See Definition of

Identity Error % - Line Performance). 4

– Rejected:

Number of components that have been rejected by the Placement station during the day. 4
