A-6 Appendix Position Name Part Name Part No. Note Qty X/Y -axis Y -axis cable carrier chain links LINK, 70 CABLE Y KMB-M26H1-00X 4-beam type Set per machine 1 LINK, 90 CABLE Y KMB-M26H1-10X 2-beam type Set per machine 1…
A-5
Appendix
2. Maintenance parts
2.1 YSM40R main unit maintenance parts list
c
CAUTION
The parts (part Nos.) in this manual were described at the time of manual issue. The part Nos. are subject to change
without notice. Make sure to obtain the latest information on part names and part Nos. when purchasing.
n
NOTE
• The consumable part positions and the replacement procedure are described in this manual.
• See "2.1 Consumable parts" in Chapter 1 for nozzle consumable parts.
n
Consumable parts list
Position Name Part Name Part No. Note Qty
RS head unit
Air filter FILTER
KMB-M7070-00X 1 pc 18
*1
KMB-M3857-01X 1000 pcs per set -
*1
Packing assembly PACKING ASSY KMB-M70SP-00X
RS head vacuum line
replacement part
1
*1
Blow valve for ROD1/2 VALVE KMB-M7055-00X 2
*1
MU head unit
Nozzle leaf spring LEAF SPRING KG7-M7137-A0X 20
*1
Nozzle leaf spring mounting
screw
SCREW,PAN HEAD 90990-08J016 M2 x L2.5 20
*1
Air filter FILTER KLF-M7156-00X 10
*1
FL head unit
Nozzle leaf spring PLATE, SPRING KV7-M8171-00X 4
*1
Nozzle leaf spring mounting
screw
BOLT HEX,
SOCKETHEAD
90115-02J004 4
*1
Nozzle leaf spring mounting
washer
WASHER, PLAIN 90990-28J002 4
*1
Air filter FILTER KLF-M7156-00X 2
*1
Conveyor belt
Conveyor belt
BELT, CONVEYOR 1 KLF-M9110-00X [Lane 1] Length: 1180 mm 4
*2
BELT, CONVEYOR 2 KLF-M9117-00X [Lane 1] Length: 1256 mm 4
*2
BELT, CV1 KLF-M9177-01X
For extension conveyor
Length: 1524 mm
4
*3
Base
Controller filter
MEDIA FILTER KLA-M53A9-00X For system controller 1
FILTER KLA-M53A8-00X For servo controller 1
Ceiling fan filter FILTER,TOP COVER FAN KLF-M130J-00X 2
Conveyor I/O filter FILTER,CP,FAN KLF-M115J-00X 1
Rear base fan filter FILTER,REAR BASE FAN KLF-M131J-00X 1
Filter element (air filter) FILTER ELEMENT KLF-M8502-50X Air filter 1
Element assembly
(Oil mist filter)
MIST FILTER ELEMENT KLF-M8502-70X Oil mist filter 1
A-6
Appendix
Position Name Part Name Part No. Note Qty
X/Y-axis
Y-axis cable carrier chain links
LINK, 70 CABLE Y KMB-M26H1-00X
4-beam type
Set per machine
1
LINK, 90 CABLE Y KMB-M26H1-10X
2-beam type
Set per machine
1
Vacuum pump
Vacuum pump maintenance
set
PUMP SPARE SET
KLF-M86P0-00X
For a 4-beam type machine
(2 pumps)
1
KLF-M86P0-10X
For a 2-beam type machine
(1 pump)
1
Ionizer
(option)
Ionizer discharge needle set
(4 per set)
Needle Set KHN-M83P1-00X 1
*4
UPS
(option)
UPS battery UPS,BATTERY KGA-M6566-30X 1
*1
Required quantity per head unit
*2
Required quantity for each lane
*3
Required quantity per machine when one side is extended
*4
Required quantity per ionizer
A-7
Appendix
n
Maintenance parts list for
YSM40R
Position Name Part Name Part No. Note Qty
RS head
unit
Sensor
Vacuum sensor SEN.VAC.PRESS ASSY KMB-M653P-00X 1
*1
N-axis origin sensor SENSOR,N ORG ASSY KMB-M653M-00X 1
R-axis origin sensor SENSOR,R ORG ASSY KMB-M653N-00X 1
Shaft/Holder
Nozzle shaft
(for odd number shafts)
SHAFT 1,SPARE KMB-M701S-A0X 9
Nozzle shaft
(for even number shafts)
SHAFT 2,SPARE KMB-M702S-A0X 9
Nozzle holder assembly HOLDER NOZZLE ASSY. KMB-M703S-A0X Nozzle shaft tip 18
Motion part
Z-axis motor assembly Z AXIS ASSY. KMB-M70K0-00X Z-axis motor 2
V-axis motor assembly V AXIS ASSY. KMB-M70R0-00X V-axis motor 2
R-axis motor AC SERVO MOTOR 90KD0-011504 R-MOTOR 1
N-axis motor AC SERVO MOTOR 90KD0-012003 N-MOTOR 1
Camera
Side-view camera
assembly
S.V.CAM.ASSY. KMB-M79C0-H1X Side-view camera 1
Valve
Blow pressure switch
valve
VALVE KMB-M7053-00X 1
Vacuum switch valve VALVE KMB-M7052-00X 1
Assembly
Rotary assembly ROTARY ASSY. KMB-M7010-00X
Rotary assembly
(18 nozzle shafts &
nozzle holder assembly)
1
RS head unit RS HEAD UNIT KMB-M70U0-00X
Spare RS unit
1 set of unit
1
MU head
unit
Sensor
Flow sensor for H7-H10 SENSOR FLOW.1 ASSY KLF-M654D-02X 4
*1
Flow sensor for H1-H6 SENSOR FLOW.2 ASSY KLF-M654D-12X 6
Vacuum sensor SENSOR PRESS. ASSY KLF-M654C-00X 1
Shaft
Spline shaft
(H1,3,4,6)
SHAFT 1,SPARE KLF-M711S-A0X For head 1/3/4/6 4
Spline shaft
(H2,5,7,8,9,10)
SHAFT 2,SPARE KLF-M712S-A0X For head 2/5/7/8/9/10 6
Motion part
R-axis motion belt 1 BELT 1 KLF-M7131-00X 2
R-axis motion belt 2 BELT 2 KLF-M7132-00X 2
Motion part air tube 1 TUBE(TUS0425N) KLF-M712A-00X 6
Motion part air tube 2 TUBE(TUS0425N) KLF-M712B-00X 4
Motion part air tube 3 TUBE(TUS0425N) KLF-M712C-00X 10
Motion part air tube 4 TUBE(TUS0425N) KLF-M712D-00X 4
Z-axis assembly (rear) Z AXIS ASSY.1 KLF-M71K0-00X
For rear head
(7,8 & 9,10)
2
Z-axis assembly (front) Z AXIS ASSY.2 KLF-M71L0-00X
For front head
(1,2,3 & 4,5,6)
2
R1-axis motor
AC SERVO MOTOR
ASSY
90KB0-113503 R1 1
R2-axis motor
AC SERVO MOTOR
ASSY
90KB0-113504 R2 1
Valve
Blow valve VALVE KLF-M7152-00X For MU unit head 10
Vacuum switch valve VALVE KLF-M7153-00X For MU unit head 10
Joint
Joint JOINT KLF-M7154-00X 10
Filter joint FILTER JOINT KLF-M7155-00X 10
Assembly MU head unit MU HEAD UNIT KLF-M71U0-00X
Spare MU unit
1 set of unit
1
