1-1
1
Maintenance
1. Maintaining machine performance
The most important condition essential for maintaining the performance of the machine you purchased is
using it under good environmental conditions. Performing daily maintenance and periodic inspections is also
absolutely essential.
1.1 Essential conditions and working environment
n
Air
Item Description
Air pressure
Supply air pressure: 0.45MPa or more
Setting air pressure: 0.40MPa (0.39MPa to 0.41MPa)
Head unit air pressure: 0.040MPa (0.039MPa to 0.041MPa)
Air consumption
RS head (4-beam type) : 50Nl/min (average), 180Nl/min (max.)
MU head (2-beam and 4-beam types) : 30Nl/min (average), 140Nl/min (max.)
FL head (2-beam) : 30Nl/min (average), 140Nl/min (max.)
Use conditions
Air hose with inner diameter of 8mm or more should be used.
Clean air passed through air dryer and air filter should be used.
n
Power
Item Description
Power supply 200/208/220/240/380/400/416VAC (±10%), 3-phase AC line
Frequency 50Hz or 60Hz
Power supply capacity 13.9KVA
Average power consumption 3.2KW
Power supply connection Power cable conductor cross-section area: 10mm
2
minimum
n
Environment
Item Description
Noise Complies with EN61000-6-2 standard.
Humidity 20 to 80% (no condensation), optimal range: 50 to 60%
Temperature Functions guaranteed within 15 to 35°C. Machine precision guaranteed within 20 to 28°C.
Overvoltage category category III
Pollution degree degree 2
Altitude 1000 m or less above sea level
Installation
Flat level location sturdy enough so no vibration occurs during operation.
Wooden floors in particular are unsuitable.
Required floor flatness
When using feeder exchange carriages on the front and rear of the machine, the flatness
of the floor must be within 10 mm, including the area directly under the machine..
Floor load-bearing strength 1000kg/m
2
or more
n
NOTE
When using an industrial humidifier as static electricity prevention measures, be sure to use water equivalent to the DI
water.
1-2
1
Maintenance
1.2 Importance of periodic inspections and cleaning
Periodic inspections and cleaning are extremely important maintenance tasks. Failure to perform inspections
and cleaning will prevent the machine from delivering full performance and may lead to component mounting
problems or equipment breakdowns.
Examples:
• Dirty nozzles might cause mistakes in component recognition and cause mounting errors.
• Dirty air paths may cause numerous pickup and mounting errors.
• Inadequate feeder and feeder plate inspections may cause pickup errors.
• Dirty optical system (camera, lighting, etc.) may cause recognition errors.
• Poor greasing of axes may cause abnormal noises.
• Poor inspections such as of valves may cause errors in PCB clamping and conveying.
As these examples show, failure to make inspections may lead to equipment problems. It is strongly
recommended to perform periodic inspections and cleaning to ensure the machine is used under optimal
conditions.
n
NOTE
The "inspection check sheet", a list of inspection items is included at the end of this manual for effective inspection.
Use the check sheet when inspecting.
1-3
1
Maintenance
2. Preparing for maintenance tasks
Tasks described in this section focus mainly on replacing parts (consumable parts) that might cause a gradual
loss of machine functions during use. This section also describes how the user can easily replace parts
(replaceable parts) when a breakdown occurs.
2.1 Consumable parts
The term "consumable parts" in this manual indicates parts subject to continual wear during use causing
gradual loss of functions. The following parts are classified in this manual as consumable parts and should be
replaced as needed during maintenance.
2.1.1 MU head unit
n
Consumable parts (parts supplied with machine)
Consumable parts (MU head)
Parts supplied with machine
Air filter
Nozzle leaf spring
Nozzle leaf spring
mounting screw
53100-N9-00
Name Part Name Part No. Note
Nozzle leaf spring LEAF SPRING KG7-M7137-A0X
Nozzle leaf spring mounting screw
SCREW, PAN HEAD 90990-08J016 M2 × L2.5
Air filter FILTER KLF-M7156-00X
c
CAUTION
The parts (part Nos.) in this manual are at the time of issuing this manual. The part Nos. may be changed without prior
notice. Make sure to verify the latest part Nos. before ordering.
