4. Lubricating points/schedule (cA TS) 5-13 4.1 AZ-axis 5-13 4.2 AH-axis 5-14 4.3 Pickup station and others 5-15 4.4 Both sides of cA TS 5-16 Chapter 6 How to replace consumable par ts 1. Replacing the leaf spring and ro…
Chapter 4 Maintenance of options
1. Ionizer 4-1
1.1 Cleaning ionizer discharge needle (Monthly) 4-2
1.2 Replacing ionizer discharge needle (2-year) 4-3
2. UPS (Uninterruptible Power Supply) 4-4
2.1 Replacing the UPS battery (3 year) 4-4
3. Inspecting, cleaning and lubricating cATS 4-5
3.1 Daily inspection 4-6
3.1.1 Inspecting magazines and pallets 4-6
3.2 Monthly inspection 4-7
3.2.1 AZ-axis 4-7
3.2.2 Both sides of cATS 4-7
3.3 6-month inspection 4-8
3.3.1 AH-axis 4-8
3.3.2 Magazine shaft 4-8
3.3.3 Pickup station (pallet clamp) 4-9
3.3.4 Pickup station (vertical guide) 4-9
4. Nozzle station 4-10
4.1 Checking nozzle station sensor (1-year) 4-10
4.2 Cleaning nozzle station 4-12
Chapter 5 Lubricating points
1. Lubricating preparations 5-1
1.1 Compatible grease 5-1
1.2 Grease gun 5-2
2. Lubricating points/schedule (Main machine) 5-3
2.1 X-axis 5-3
2.1.1 4-beam type 5-3
2.1.2 2-beam type 5-4
2.2 Y-axis 5-5
2.2.1 4-beam type 5-5
2.2.2 2-beam type 5-6
2.3 W-axis 5-7
2.4 PU-axis 5-8
2.5 Head unit 5-9
2.5.1 MU head unit 5-9
2.5.2 RS head unit 5-10
2.5.3 FL head unit 5-11
3. Lubricating points/schedule (Carriage) 5-12
3.1 Feeder exchange carriage 5-12
4. Lubricating points/schedule (cATS) 5-13
4.1 AZ-axis 5-13
4.2 AH-axis 5-14
4.3 Pickup station and others 5-15
4.4 Both sides of cATS 5-16
Chapter 6 How to replace consumable parts
1. Replacing the leaf spring and roller lock 6-1
1.1 Replacing nozzle leaf springs (MU head) 6-1
1.2 Replacing nozzle leaf springs (FL head) 6-3
1.3 Replacing the roller lock (FL head) 6-4
2. Replacing conveyor belt 6-5
2.1 Replacing the conveyor belt 6-5
3. Replacing the nozzle tip 6-8
3.1 Replacing nozzle tip and spring 6-8
3.2 Replacing nozzle O-ring 6-9
Appendix
1. Specifications A-1
1.1 Air regulator unit A-1
1.2 Power connection terminals A-2
1.3 Connection between machines A-3
1.3.1 PREVIOUS INTERFACE connector A-3
1.3.2 NEXT INTERFACE connector A-4
2. Maintenance parts A-5
2.1 YSM40R main unit maintenance parts list A-5
2.2 Tray component supply unit maintenance parts list A-14
The instruction manual of this machine is written for those who operate
this machine.
Please read this manual carefully for correct operations and pay
special attention to safety precautions.
After reading through this manual, please use this manual as an
occasional reference and keep it within reach.
Introduction
Contents
1. About this manual i
2. Maintenance list ii
