A-10 Appendix Position Name Part Name Part No. Note Qty Feeder exchange carriage Feeder plate 12-position feeder guide rail (rear) 1 RAIL GUIDE 12P KHY -M371R-00X 3 *7 12-position feeder guide rail (rear) 2 RAIL GUIDE 12…
A-9
Appendix
Position Name Part Name Part No. Note Qty
Recognition
unit
Multi-camera
Side-view camera
moving up sensor
SEN.SV UP ASSY KMB-M654A-00X
Multi-camera without
coplanarity checker for
YSM40R-4
1
*4
Side-view camera
moving down sensor
SEN.SV LOW ASSY KMB-M654A-10X 1
Side-view camera
moving up sensor
SEN.SV UP ASSY KMB-M654B-00X
Multi-camera with
coplanarity checker for
YSM40R-4
Multi-camera for
YSM40R-2 (common in
with/without coplanarity
checker)
1
Side-view camera
moving down sensor
SEN.SV LOW ASSY KMB-M654B-10X 1
ANC
Nozzle station
base (common)
ANC base valve assembly
(YSM40R-4)
VALVE ASSY KMB-M653E-00X 1
ANC base valve assembly
(YSM40R-2)
VALVE ASSY KLF-M961A-00X 1
ANC
(For RS head
unit)
ANC moving up sensor SEN.ANC UP ASSY KMB-M653H-00X 1
*5
ANC moving down sensor SEN.ANC DOWN ASSY KMB-M653H-10X 1
ANC shutter open sensor SEN.ANC OPEN ASSY KMB-M653J-00X 1
ANC shutter close sensor SEN.ANC CLOSE ASSY KMB-M653J-10X 1
ANC top/bottom cylinder
CYL,ANC UP/DOWN
ASSY
KMB-M653F-00X
ANC top/bottom
cylinder section
1
ANC shutter open/close
cylinder
CYL.ANC OP/CL ASSY KMB-M653G-00X
ANC shutter open/close
cylinder section
1
ANC head unit for RS
head unit
ANC RS UNIT KMB-M96U0-A0X ANC unit for RS 1
ANC
(For MU/FL unit)
ANC moving up sensor SENSOR ANC UP ASSY KLF-M653T-00X 1
ANC moving down sensor
SENSOR ANC DOWN
ASSY
KLF-M653T-10X 1
ANC shutter open sensor
SENSOR ANC OPEN
ASSY
KLF-M653S-00X 1
ANC shutter close sensor SENSOR ANC CL. ASSY KLF-M653S-10X 1
ANC top/bottom cylinder CYLINDER KLF-M965B-00X
ANC top/bottom
cylinder section
1
ANC shutter open/close
cylinder
CYLINDER (MBDAS) KKU-M184K-00X
ANC shutter open/close
cylinder section
1
ANC head unit for MU
head unit
ANC MU UNIT KLF-M96U0-B0X ANC head unit for MU 1
ANC head unit for FL
head unit
ANC FL UNIT KLF-M96U0-C0X ANC head unit for FL 1
PU-axis
PU-axis moving
section
(for all tables)
PU-axis motor
motion belt
BELT 342-EV3GT-15 RF KLF-M921D-00X 1
*6
PU-axis motor
motion pulley
PULLEY 1:P22-3GT KV7-M9205-01X 1
Motion pulley mounting
bolt
BOLT HEX,SOCKET
HEAD
91312-04012 1
Motion pulley mounting
washer
WASHER, PLAIN 90990-28J076 1
Drive unit pulley PULLEY:P60-3GT KHW-M9215-00X 1
Drive unit pulley mounting
bolt
BOLT HEX,SOCKET
HEAD
91312-04012 3
Drive unit pulley bearing BEARING 90933-01J007 2
Drive unit pulley circlip CIRCLIP 90440-01J090 1
A-10
Appendix
Position Name Part Name Part No. Note Qty
Feeder
exchange
carriage
Feeder plate
12-position feeder guide
rail (rear) 1
RAIL GUIDE 12P KHY-M371R-00X 3
*7
12-position feeder guide
rail (rear) 2
RAIL GUIDE 12P KLF-M375H-00X 1
Guide rail mounting bolt SCREW, FLAT HEAD 98702-03006 40
12-position feeder guide
rail (center) 1
GUIDE,FEEDER UNDER KHY-M372R-00X Guide rail (center) 1 3
12-position feeder guide
rail (center) 2
GUIDE,FEEDER UNDER KLF-M375N-00X Guide rail (center) 2 1
12-position feeder guide
rail (outer) 1
GUIDE,FEEDER UNDER KLF-M375X-00X Guide rail (outer) 1 3
12-position feeder guide
rail (outer) 2
GUIDE,FEEDER UNDER KLF-M375X-50X Guide rail (outer) 2 1
Guide rail mounting bolt SCREW, BINDING HEAD 98902-03004 Bolt 101
Cam follower
Feeder exchange carriage
cam follower (rear right)
CAM FOLLOWER KLF-M3763-00X
Cam follower
(rear right)
1
Feeder exchange carriage
cam follower
(left&right of center)
CAM FOLLOWER KKU-M1138-00X
Cam follower
(left&right of center)
2
Base
Blow station
Filter (for YSM40R-2) FILTER,SPARE KGR-M9934-F0X 1
*8
Filter (for YSM40R-4) ELEMENT,SPARE KLW-M99B5-F0X 1
Valve (for YSM40R-2) VALVE ASSY. KLF-M9906-A0X 1
Valve (for YSM40R-4) BLOW VALVE ASSY. KLW-M99V1-A0X 1
Air filter
Filter element
(air filter)
FILTER ELEMENT KLF-M8502-50X Air filter 1
Element assembly
(
oil mist filter
)
MIST FILTER ELEMENT KLF-M8502-70X Oil mist filter 1
Tape cutter
46-position tape cutter
lower blade set
CUTTER,LOWER 46 KLF-M3T07-A0X Cutter lower blade set 1
*9
46-position tape cutter
upper blade set
CUTTER,UPPER 46 KLF-M3T05-00X
Cutter upper blade
(common in left/right)
Requires 2 per bank
2
Tape cutter damper SHOCK ABSORBERS KHY-M3T22-01X Damper 2
A-11
Appendix
Position Name Part Name Part No. Note Qty
YSM40R-4
Y-axis
Y-axis duct
(all tables for
YSM40R-4)
Center tape for protecting
cable
TAPE,Y DUCT 1 KMB-M260B-01X 1
*1
Outer periphery tape for
protecting cable
TAPE,Y DUCT 2 KMB-M260C-01X 1
Inner periphery tape for
protecting cable
TAPE,Y DUCT 3 KMB-M260D-01X 1
Tape support plate PLATE, NUT KMB-M2666-01X 2
Harness mounting
bracket 1
BRACKET,1 HARNESS KMB-M2668-01X 1
Harness mounting
bracket 2
BRACKET,2 HARNESS KMB-M2669-01X 1
Y-axis cable duct CABLE DUCT,Y KMB-M2617-01X Set of cable ducts 1
Mounting bolt
BOLT HEX.SOCKET
HEAD
90990-01J011 2
Mounting bolt
BOLT HEX.SOCKET
HEAD
90990-01J032 2
Mounting bolt
BOLT HEX.SOCKET
HEAD
91312-05014 8
Mounting screw SCREW, BINDING HEAD 98902-03006 4
Flat harness in Y-axis
duct
HNS,XY-FLEX KMB-M66N1-00X
J0071-J0074
Flat harness for
camera, I/O, etc.
1
Y-axis encoder cable in
Y-axis duct
HNS,Y-FLEX YP KLF-M66AN-00X J0125-J0128 1
Y-axis motor cable in
Y-axis duct
HNS,Y-FLEX YM KLF-M66E4-00X J0155-J0158 1
X-axis motor cable in
Y-axis duct
HNS,Y-FLEX XM KLF-M66E5-00X J0159-J0162 1
X-axis encoder cable in
Y-axis duct
HNS,Y-FLEX XP KMB-M66A2-00X J0129-J0132 1
X-axis DI cable in Y-axis
duct
HNS,Y-FLEX X DI KMB-M66G4-00X J0322-J-325 1
Ground wire in Y-axis duct HNS,EARTH 90K30-544150 1
Y-axis
(For YSM40R-4)
Y-axis linear guide (top) GUIDE,30 Y AXIS KLF-M2610-03X 1
Guide mounting bolt
BOLT,HEX.SOCKET
HEAD
91312-08025 24
Bolt cap CAP C8 90K81-200009 24
Y-axis linear guide (side) GUIDE,25 Y AXIS KMB-M2611-00X 1
Guide mounting bolt
BOLT,HEX.SOCKET
HEAD
91312-06020 31
Bolt cap CAP 90K81-210206 31
YSM40R-4
X-axis
X-axis
(For YSM40R-4)
X-axis ball screw BALL SCREW KMB-M2212-00X 1
X-axis support SUPPORT UNIT KMB-M2213-00X 1
X-axis spacer SPACER KHN-M224D-00X 1
X-axis lock nut LOCK NUT KGS-M2628-00X 1
X-axis bearing BEARING 90933-01J300 1
X-axis circlip CIRCLIP 99009-10400 1
X-axis
(For YSM40R-4)
X-axis linear guide GUIDE SET,X AXIS KMB-M2211-00X 1
Guide mounting bolt
BOLT HEX.SOCKET
HEAD
91312-04016 14
Bolt cap CAP C4 90K81-200004 14
