3.2 Example 2 (Example of Placement Data Creation)
2-96
Fig. 2B142
Notes: (a) Component placement coordinates must be measured from the
pattern origin.
(b) P
0
shows the P.C.B. positioning reference.
(c) “O-0001”, “O-0002”, “O-0003”, “O-0004”, “O-0005”, and “O-
0006” are called “Pattern Origins”. Each coordinate measured from
the P.C.B. positioning reference point must be entered.
(d) Measure the coordinates (distances) based on the pattern origins
and enter them for component placement.
Fig. 2B141
0305-001 Tg0858-PM-PM
3.2 Example 2 (Example of Placement Data Creation)
(2) Example of Data Creation
Use placement data (P) U01 and placement data (O) U01.
Placement Data (P) U01
Enter “0” (zero) in all data fields of the last step and “E” as a
control command.
Enter “0” (zero) in all data fields of the last step and “P” or
“Q” as a control command.
Placement Data (O) U01
P-NO. X(mm) Y(mm) Z(THETA) H(mm) FDR S V C COMMENT
0000 +0.00 +0.00 +0°00’ +0.00 000 - 00 -
0001 +5.00 +20.00 +0°00’ +0.00 101 - 00 -
0002 +15.00 +10.00 +180°00’ +0.00 201 - 00 -
0003 +25.00 +10.00 +90°00’ +0.00 301 - 00 -
0004 +0.00 +0.00 +0°00’ +0.00 000 - 00 P
O-NO. X(mm) Y(mm) Z(THETA) H(mm) C COMMENT
0000 +0.00 +0.00 +0°00’ +0.00 -
0001 +5.00 +5.00 +0°00’ +0.00 -
0002 +65.00 +35.00 +180°00’ +0.00 -
0003 +5.00 +40.00 +0°00’ +0.00 -
0004 +65.00 +70.00 +180°00’ +0.00 -
0005 +100.00 +5.00 +270°00’ +0.00 -
0006 +70.00 +65.00 +90°00’ +0.00 -
0007 +0.00 +0.00 +0°00’ +0.00 E
2-97
Table 2B47
Table 2B48
0305-001 Tg0858-PM-PM
3.3 Pattern Program Data Sheet
2-98
3.3 Pattern Program Data Sheet
Before creating or editing pattern program data, refer to the detailed descrip-
tion of each data editing in items (2.2) and (2.3) and fill in this sheet (attached
at the end of this manual) with required parameters.
Fig. 2B143
OPERATION DATA
PROGRAM NAME
COMMENT #1
COMMENT #2
DATE OF PREP
PREPARED BY
COMPONENT DATA (TAPE FEEDER)
PROGRAM NAME
COMMENT #1
COMMENT #2
DATE OF PREP
PREPARED BY
PLACEMENT DATA (P) UA
PROGRAM NAME
COMMENT #1
DATE OF PREP
PREPARED BY
PLACEMENT DATA (V) UA
COMMENT #2
