Page 12
SAFETY PRECAUTIONS
Be sure to observe
DANGER
4H4C-E-OMA00-A03-01
L06EB
DO NOT OPEN THE
COVER WHEN OPER-
ATING.
You will have serious injury if
you touch the active part inside.
L02E
DO NOT TOUCH AC-
TIVE PART WHEN
OPERATING.
You will have serious injury if
you touch the active part.
Page 13
SAFETY PRECAUTIONS
Be sure to observe
E
M
E
R
G
E
N
C
Y
S
T
O
P
2
Emergency stop button
(At the rear side)
If you sense any danger or abnormality, press an emergency stop button to
stop the machine.
If you continue to operate the machine in a dangerous or abnormal state, a breakdown or an
accident will occur.
There are two emergency stop buttons on CM301-D. Pressing any one of them stops operation.
Press the nearest
one.
Remove the cause of the danger or abnormality, then re-start operation.
To reset the emergency
stop button, pull it.
M104E
WARNING
E
M
E
R
G
E
N
C
Y
S
T
O
P
4H4C-E-OMA00-A03-00
1
Emergency stop button
(At the front side)
E
M
E
R
G
E
N
C
Y
S
T
O
P
CM301-D
4H4C-AA01
Page 14
SAFETY PRECAUTIONS
Be sure to observe
If you sense any danger or abnormality, press an emergency stop button to
stop the machine.
If you continue to operate the machine in a dangerous or abnormal state, a breakdown or an
accident will occur.
There are two emergency stop buttons on CM301-DU. Pressing any one of them stops operation.
Press the nearest
one.
Remove the cause of the danger or abnormality, then re-start operation.
To reset the emergency
stop button, pull it.
M104E
E
M
E
R
G
E
N
C
Y
S
T
O
P
E
M
E
R
G
E
N
C
Y
S
T
O
P
1
Emergency stop button
(At the front side)
2
Emergency stop button
(At the rear side)
CM301-DU
4X4C-AA00
WARNING
E
M
E
R
G
E
N
C
Y
S
T
O
P
4H4C-E-OMA00-A03-00
