Page 1-1 4H4C-E-OMA01-A01-00 Chapter 1 GENERAL DESCRIPTION General Description This chapter describes the following. Names and Mechanism of Each Unit This describes the names and mechanism of each unit by using illustrat…
Page 42
NOTICE
This manual is created for CM301-D and CM301-DU. Therefore it mainly uses the
illustrations and screens of CM301-D for description.
HOW TO SEE DESCRIPTION FOR OPERATION
CE Specification
CM301-D
Front view
Rear view
Standard Specification
4H4C-AG00
4H4C-AH00
External view Specification
Front view
4M4C-AD00
Rear view
4M4C-AA00
DT40T-40
CM301-DU
Front view
Rear view
4X4C-AA00 4X4C-AB00
Front view
4M4C-AD00
Rear view
4M4C-AA00
DT40T-40U
∗ For further information about the specification, see “1-3 Equipment Specification” in the Operating Manual.
4H4C-E-OMA00-A04-00
Page 1-1
4H4C-E-OMA01-A01-00
Chapter 1
GENERAL DESCRIPTION
General Description
This chapter describes the following.
Names and Mechanism of Each Unit
This describes the names and mechanism of each unit by using illustrations.
Production Process
This describes the mounting process in due order.
Specification
This describes the specification of the equipment and available boards.
4H4C-AD00
Page 1-2
4H4C-E-OMA01-A01-01
1-1 Names and Mechanism of Each Unit
1-1-1 Placement Machine (CM301)
External View
Front View
Status Indicator
(3-color Indicator Light)
Front Panel
Power Supply Switch
Rear View
Feeder Table
Front Safety Cover
Rear Panel
Rear Safety Cover
Rear Side Cover
4H4C-AA01
4H4C-AB01
Front Side Cover
Side Safety Cover
