Page 42 NOTICE This manual is created for CM301-D and CM301-DU. Therefore it mainly uses the illustrations and screens of CM301-D for description. HOW T O SEE DESCRIPTION FOR OPERA TION CE Specification CM301-D Front vie…
4
Page 41
4H4C-E-OMA00-A04-00
HOW TO SEE DESCRIPTION FOR OPERATION
The description depends on each page, but the basic structure is as follows.
1-1-1 Starting Production
1. Press
Production
.
•“Return to origin” for all axes are carried out.
MARKS USED IN THIS MANUAL
In this manual, the following mark are used for description.
Title
Actual operation
Supplementary description
Operation step number
: Shows operation flow.
: Shows a reference item.
: Shows the operation for engineers.
: Shows the operation for operators.
: Shows pressing a key on the touch
panel.
: Means pressing
UNLOCK
and then
START
on the operating panel within
2 seconds.
: Means pressing B key while
holding A key.
A B
+
Return
UNLOCK
START
Engineer
Operator
Page 42
NOTICE
This manual is created for CM301-D and CM301-DU. Therefore it mainly uses the
illustrations and screens of CM301-D for description.
HOW TO SEE DESCRIPTION FOR OPERATION
CE Specification
CM301-D
Front view
Rear view
Standard Specification
4H4C-AG00
4H4C-AH00
External view Specification
Front view
4M4C-AD00
Rear view
4M4C-AA00
DT40T-40
CM301-DU
Front view
Rear view
4X4C-AA00 4X4C-AB00
Front view
4M4C-AD00
Rear view
4M4C-AA00
DT40T-40U
∗ For further information about the specification, see “1-3 Equipment Specification” in the Operating Manual.
4H4C-E-OMA00-A04-00
Page 1-1
4H4C-E-OMA01-A01-00
Chapter 1
GENERAL DESCRIPTION
General Description
This chapter describes the following.
Names and Mechanism of Each Unit
This describes the names and mechanism of each unit by using illustrations.
Production Process
This describes the mounting process in due order.
Specification
This describes the specification of the equipment and available boards.
4H4C-AD00
