SERIAL PLATE
The serial plate attached to this machine indicates the model name and production number.
4X4C-AB00
CM301-DU
CM301-D
4H4C-AB01
4H4C-E-OMA00-A04-05
Actual numbers are shown on the plate instead of ∗.
Actual numbers are shown on the plate instead of ∗.
CM301-D
KXF-4H4C
CM301-DU
KXF-4X4C
Page 40
DISPOSING OF THE AIR SPRING
This machine uses the air spring to open/close covers. It is very dangerous to dispose of it as it is,
because high-pressure air is sealed into it. Before disposing of it, be sure to bleed it of the air.
Removing the air spring
Turn the bolt with hexagonal hole counterclockwise, and remove the spring.
Discharging of the air spring
Drill the spring and discharge the air in it completely.
NOTICE
As crashed chips and oil discharge when the air is coming out, use safety glasses
for protection.
1B4C-442E
1D4C-406E
4H4C-AB01
Bolt with hexagonal hole
Air spring
Position to drill the air spring
15 mm to 20 mm
Hole
Position to use the air spring
ABOUT DISPOSAL OF COMPONENTS CONTAINING MERCURY
NOTICE
This product has a fluorescent lamp that contains a small amount of mercury.
It also contains lead in some components. Disposal of these materials may be
regulated in your community due to environmental considerations.
For disposal or recycling information please contact your local authorities, or the
Electronics Industries Alliance.
4H4C-E-OMA00-A04-01
