Page 3-4 3-2 Production Settings This is used for the settings requisite for production and to check the motion. 1. Press Product config on the main menu. •“ Production config menu ” is displayed. ∗ Pressing a function s…
Page 3-3
FUNCTIONS
3
4H4C-E-OMA03-A01-00
3-1-2 Engineer Mode
Menu Configuration
Engineer
Data modify
Describes customizing the functions of the operator mode.
3-5-6Customizing Operator Mode
Describes setting the time of the machine.
3-5-4Setting Time
Describes specifying and resetting defective nozzles.
3-5-3Defective Head
Describes checking nozzle stock data.
7-7Nozzle Stock Data
Describes checking and modifying mount data.
7-9Mount Data
Describes checking production data.
7-12Data Check
Describes checking and modifying board data.
7-2PCB Data
Describes checking nozzle arrangement data.
7-6Nozzle Arrangement Data
Describes teaching production data.
Chapter 8TEACHING
Describes checking and modifying board recognition data.
7-3Board Recognition Data
Describes checking feeder layout list and stock data.
7-4Feeder Layout / Stock Data
Describes checking the settings of function switches.
7-10Function Switch
Describes checking and modifying block attribute data.
7-8Block Attribute Data
Describes checking the correction value by pick-up position learning.
3-5-2Pick-up Position Learning
Describes changing the conditions for the motions for production.
3-5-1Switches for Adjustment
Describes loading/saving machine parameters.
Chapter 6Sub operation
Describes loading production data.
Chapter 6Main operation
Refer to the Mainte-
nance Manual.
File
managment
Machine
parameter
Machine
config
Machine
adjust
Displays the tape feeder library data.
7-11Feeder Library
Displays the recognition library data.
7-11Recognition Library
Displays the nozzle library data.
7-11Nozzle Library
Describes displaying the input addresses in bit.
3-4-7Input Check
Describes checking recognition processing motion.
APPENDIX A
RECOGNITION DEVICE
Describes returning all axes to their origins.
3-4-1Returning to Origin
Describes adjusting the width of conveyor.
3-4-2Conveyor Width Adjustment
Describes transporting board onto conveyor.
3-4-3Board Transport
Describes changing nozzles.
3-4-4Nozzle Changing
Describes displaying the load onto ring.
3-4-11Ring Load Information
Describes checking the state of valve and working it.
3-4-8Output Check
Describes checking the current positions and states of all axes.
3-4-9Axis Information
Describes pick-up, recognition and mounting motions.
3-4-5Pick-up and Mounting Motions
Describes drawing out the tray pallet.
3-4-6Tray Adjustment
Describes setting the backlight-off time.
3-5-5Setting Backlight
Page 3-4
3-2 Production Settings
This is used for the settings requisite for production and to check the motion.
1. Press
Product
config
on the main menu.
•“Production config menu” is displayed.
∗ Pressing a function switch displays each
setting screen.
4H4C-E-OMA03-A01-02
Page 3-5
FUNCTIONS
3
3-2-1 Nozzle Settings
You can check the nozzle arrangement of each head.
The names of the nozzles attached to each head currently are displayed.
• Press the head you would like to check.
∗ For information about how to change nozzles,
see “9-4 Nozzle Exchange”.
NOTICE
Take care not to misset the nozzle, or it will be damaged.
For example, when the nozzle is set on the head, the No. 11 on the nozzle changer is vacant.
If another nozzle is set in the No. 11 by mistake, the nozzles will collide with each other because the
machine will put the nozzle on the head back to the No. 11 in changing nozzles.
Production Settings
4H4C-E-OMA03-A01-03
