Page 1-6 Z Unit Moves the head unit upward and downward. Names and Mechanism of Each Unit Line Camera (T wo in All) Used to recognize chips. This can recognize all the chips from minute ones to large-sized and unusual-sh…
Page 1-5
GENERAL DESCRIPTION
1
Names and Mechanism of Each Unit
Main Units
Head Unit (Two in All)
Consists of a head camera and two transfer heads.
Board Conveyor
Transports boards in and out.
010WC0AA01
4H4C-018E
160JC0AA01
030CC0AA01
4H4C-E-OMA01-A01-00
Transfer Head
Picks up chips and
mounts them onto the
board. Each head unit
has two transfer
heads.
Nozzle
Picks up chips using a
vacuum pressure.
Various sizes and
shapes of nozzles
support various chips.
Head Camera
Used for board recog-
nition, thermal correc-
tion and calibration.
444C-405E
4H4C-AI00
Page 1-6
Z Unit
Moves the head unit upward and downward.
Names and Mechanism of Each Unit
Line Camera (Two in All)
Used to recognize chips.
This can recognize all the chips from minute ones
to large-sized and unusual-shaped ones.
010VC0AA01
4H4C-AJ00
160KC0AA00
4H4C-016E
4H4C-E-OMA01-A01-01
Tape Feeder Table
This is composed of the table, where the tape
feeders are set, and the tape feeding part, which
drives feeders.
∗ The tape feeding part operates even if the
vibratory stick feeder is used; however this is not
out of order.
Page 1-7
GENERAL DESCRIPTION
1
Names and Mechanism of Each Unit
Board Holder
Fixes a board by sandwiching it between Y and Z
directions, and hold it at the mount height, during
mounting.
X-Y Unit
Moves the head unit to the appointed position
quickly and precisely.
4H4C-AK00
010UC0AA01
4H4C-E-OMA01-A01-00
Nozzle Changer (Two in All)
Changes nozzles automatically during production.
15VHC0AA01
0503C0AA01
4H4C-AL00
