4 Lifting axes Adjustment Instructions MTC 2 4.4 Guide rails and stopper bars 12/2007 Edition 52 4.4.5 Checking and setting the stopper bars, bottom (see Fig. 4.4 - 2) Move the doors fully down Remove the side covers…
Adjustment Instructions MTC 2 4 Lifting axes
12/2007 Edition 4.4 Guide rails and stopper bars
51
4.4.2 Preparatory measures
Move the lifting axis into the refill position for cassette 1 and completely set up the MTC 2 with
empty cassettes (see User Manual).
Set up every cassette with an empty WTC in the bottom and in the top level.
4.4.3 Checking and setting the guide rails, top (see Fig. 4.4 - 1)
Manually open the WTC interlock for each WTC which has been set up and check that the
WTC can be pulled out approx. 0.5 to 1mm up to the closed guide rail. When closing the WTC
interlock, the WTC must automatically click into place.
Open the guide rail. When closing the guide rail, use a WTC which has been pulled out to
check either:
– that the WTC engages in the WTC interlock again on its own or
– that the guide rail cannot be closed.
Set the position of the guide rail (by moving it in its fixing holes), if the behavior described above
is not observed.
WARNING
The guide rail must under no circumstances touch the WTCs!
4.4.4 Checking and setting the stopper bars, top (see Fig. 4.4 - 1)
Manually open the side interlock (leaf springs) for each WTC and check that the WTC can be
pushed through approx. 0.5 to 1mm up to the stopper bar. When closing the interlock, the WTC
must click into place automatically.
Set the position of the stopper bar (by moving it in its fixing holes), if the behavior described
above is not observed. If necessary, remove the covers behind the doors.
Check on tower 1 that a WTC XL with 25 mm-high components can be transported without col-
liding with the stopper bar. If necessary, correct the position of the stopper bar.
WARNING
The stopper bar must under no circumstances touch the WTCs!
4 Lifting axes Adjustment Instructions MTC 2
4.4 Guide rails and stopper bars 12/2007 Edition
52
4.4.5 Checking and setting the stopper bars, bottom (see Fig. 4.4 - 2)
Move the doors fully down
Remove the side covers
Set the position of the guide rails until they are approx. 0.5 through 1mm away from the WTCs.
WARNING
The stopper bar must under no circumstances touch the WTCs!
Fig. 4.4 - 2 Guide rails, bottom
Key
1. Guide rails
2. Attachment screws
1
2
2
2
Adjustment Instructions MTC 2 4 Lifting axes
12/2007 Edition 4.5 Cassette guide rails
53
4.5 Cassette guide rails
4.5.1 Tools and accessories
– 1 set of hexagon socket wrenches
4.5.2 Preparatory measures
NOTE
An empty cassette is needed to set the cassette guide rails.
Empty the MTC 2 completely (see the User Manual).
Prepare an empty cassette XL.
