A-1
Appendix
A1. Specifications
n
YG series specifications
Item
Specifications
YG88R YG100R YG200 (YG200L) YG300
Operating ambient temperature
Function guaranteed: 15 to 35°C
Accuracy guaranteed: 20 to 28°C
Operating ambient humidity 20 to 90% (no condensation), optimal range: 50 to 60%
Noise level 73.9dB 73.9dB 75.2dB 72.0dB
Power requirement 3-phase AC 200/208/220/240/380/416 V ± 10%, 50/60 Hz
Average power consumption
0.72 kW (main unit only)
0.90 kW (including dYTF)
0.96 kW (including sATS)
1.0kW (1.1kW) 2.6kW
Power cable (conductor cross-section
area)
3.5 mm
2
or more 6.0 mm
2
or more
Overvoltage category *
1
Category III
Pollution degree *
1
Degree 2
Supply air pressure *
2
0.55Mpa
350nl/min
0.55Mpa
400nl/min
0.55Mpa
500nl/min
Board transport height *
3
900 mm ± 10 mm
Data
Number of mounting points *
4
10,000 points
Number of part types 255 types per board
Number of fiducial marks *
5
128 sets per board
*1: Conforms to IEC60664-1.
*2: Clean, dry air passed through an air dryer and filter.
*3: Distance from the floor surface to the upper surface of conveyor belt.
*4: Decreases with the number of boards, blocks and fiducial marks.
*5: When using 2-point fiducial mode.
c
CAUTION
Conveyor's board sensors may fail to detect a production board if it has a slit or cutout.
n
NOTE
For more detailed information not listed above, please refer to specification sheets.
S-1
INDEX
Index
A
Alarm buzzer 1-2
Axis configuration 1-17
B
Blow station 1-19
Board clamping method 2-25
Board production
Ending production 3-6
Pre-operation check 2-20
Resuming operation 3-4
Starting production 3-1
Starting the machine 2-21
C
Caution labels xii
Component supply section 1-9
Connection between machines 1-3
[Convey-out stop] button 3-6
Conveyor unit 1-13
Conveyor unit setup 2-25
Conveyor unit setup flow 2-26
[Cycle Stop] button 3-6
D
Data input unit 1-4
E
Emergency stop
Canceling emergency stop 2-1
Error
Clearing an error 2-2
Errors and troubleshooting 2-3
F
Feeder exchange carriage 1-11
Feeder plate 1-9
Air connector 1-9
Feeder plate layout 1-10
Power supply connector 1-9
H
Head assembly 1-6
Eight-in-line multi-head (FNC) assembly 1-6
K
Keyboard 1-4
M
Machine main unit 1-1
Names and functions of major parts 1-1
Manual feeder operation 2-17
Manual head operation 2-16
Manual I/O operation 2-18
Modular error stop function 3-8
[Monitor] button 3-11
Mouse 1-4
N
Nozzle shaft blow 1-20
Nozzle station 1-8
Nozzle types 1-7
O
Operation panel 1-4
[READY] button 2-1
Operation panel buttons 1-5
[ACTIVE] button 1-5
[EMERGENCY STOP] button 1-5
[ERROR CLEAR] button 1-5
[READY] button 1-5
[RECOVER] button 1-5
[RESET] button 1-5
[START] button 1-5
[STOP] button 1-5
Operation screen 2-8
Main menu button area 2-8
Status area 2-8
Operation speed 3-3
[Operator] button 2-22
P
Password 2-22
Pick Rate Warning 3-25
Pickup position offset 3-23
Power switch 1-2,2-21
Turning power off 3-6
Pressure gauge 1-2
Production monitors 3-11
Push-up pins 2-27
R
Recognition system 1-13
Return-to-origin 2-21
S
Safety i
Safety cover 1-2
Safety message iii
Setup screen 2-11,3-2
[Check Nozzles] button 3-3
[Feed Bulk] button 3-3
[Measure Nozzles] button 3-3
[Required Nozzles] button 3-3
[Required Parts] button 3-2
Side-view camera 1-18
Signal light 1-2
Specifications A-1
T
Tape feeder 2-28
U
Unit screen 2-12
W
Warm_up 2-23
[Warm Up] button 2-23
Warning labels vii
"watch-and-wait" mode 3-27
