xi Safety instructions 3 . 1 . 3 H a n d l i n g o f e a c h p a r t n Wa r n i n g i n s t r u c t i o n w W ARNING KEEP A W A Y FROM FIRE. SOL VENT MIGHT CA TCH FIRE. n A p p l i c a b l e m a c h i n e s A l l s o l d…
x
Safety instructions
n
Warning instruction
w
WARNING
WHEN HANDLING TRAY MAGAZINES, NEVER PLACE HANDS IN THE MACHINE DURING OPERATION. HAND OR FINGERS
MIGHT BE CAUGHT IN MOVING PARTS AND INJURED.
n
Applicable machines Tray changer (YG series)
Pinch or crush hazard
93014-LW-00
xi
Safety instructions
3.1.3 Handling of each part
n
Warning instruction
w
WARNING
KEEP AWAY FROM FIRE. SOLVENT MIGHT CATCH FIRE.
n
Applicable machines All solder printers
Fire hazard
93021-LW-00
n
Warning instruction
w
WARNING
ALLOW ONLY PROPERLY TRAINED PERSONNEL TO EXCHANGE FEEDERS TO PREVENT POSSIBLE INJURY.
n
Applicable machines All surface mounters
Risk of injury
93022-LW-00
xii
Safety instructions
3.2 Caution labels
3.2.1 Influence on human body
n
Caution instruction
c
CAUTION
Use caution since electrical shocks might occur from touching or coming in contact with the power supply section
inside the panel.
n
Applicable machines All machines
HIGH VOLTAGE!
Electrical shock hazard
93101-LC-00
n
Caution instruction
c
CAUTION
The motor becomes extremely hot during and shortly after operation, so do not touch it!
n
Applicable machines All machines
HOT!
Possible burns if touched
93102-LC-00
