Name of Each Section Tg0869-PM-OM Multi-Layer T ray Feeder (FP-5022L) This device consists of the multi-layer tray feeder body , maga- zines, tray fixing metal and pallets, etc. 0305-001 18 Pallet (MP-5050) T ray Fixing …
Checking Item
0305-001 17 Tg0869-PM-OM
Example: Lowered Accuracy caused by the Installation
without using a level
Example: Falling due to Insufficient Floor Strength
Damage
Inaccuracy
CAUTION
CAUTION
Name of Each Section
Tg0869-PM-OM
Multi-Layer Tray Feeder (FP-5022L)
This device consists of the multi-layer tray feeder body, maga-
zines, tray fixing metal and pallets, etc.
0305-001 18
Pallet (MP-5050)Tray Fixing Metal (MF-5050L)
Grips of Magazine
Magazine (MG-5050L)
Magazine Door Fixture
Magazine DoorGrip
Grips of Magazine
Grips of Magazine
Front
Back
Roller
Anchor Bolt
Lever
Clamping Claw
Operation Monitor (Touch Screen)
Elevator
Center Cover
Upper Door
Lower Door
Lower Cover
[UPPER DOOR ELECTRO-
MAGNETIC LOCK] Switch
[U READY] Button
[LOWER DOOR ELECTRO-
MAGNETIC LOCK] Switch
[L READY] Button
Name of Each Section
Tg0869-PM-OM0305-001 19
Multi-Layer Tray Feeder (FP-5022R)
Grips of Magazine
Magazine (MG-5050R)
Magazine Door
Grip of Magazine
Grip
Magazine Door Fixture
Grip of Magazine
Tray Fixing Metal (MF-5050R)
Roller
Anchor Bolt
Lever
Clamp Claw
Pallet (MP-5050)
Front
Back
Operation Monitor (Touch Screen)
Elevator
Center Cover
Upper Door
Lower Door
Lower Door
[UPPER DOOR ELECTRO-
MAGNETIC LOCK] Switch
[U READY] Button
[LOWER DOOR ELECTRO-
MAGNETIC LOCK] Switch
[L READY] Button
