Tg0869-PM-OM 5.7 Install the device in clean air • Install the device away from flammable or corrosive gases. • Install the device away from lamp soot or dust. • • • • • Dangers caused by failure to ensure clean air • Sm…

Tg0869-PM-OM

5.6 Install the device somewhere where there is no

electrical noise

• Install the device somewhere where there is no electrical noise.

• Prevent noise with other equipment to avoid malfunction of the

device.

••

• Danger due to noise near the device

• Device malfunction might be occur due to noise.

0305-001 49

Example: Malfunction caused by Noise

CAUTION

Collision

Compulsion

Noise Prevention Measures

Beware of Noise

CAUTION

Run Away

5.6 Install the device somewhere where there is no electrical noise

Tg0869-PM-OM

5.7 Install the device in clean air

• Install the device away from flammable or corrosive gases.

• Install the device away from lamp soot or dust.

••

• Dangers caused by failure to ensure clean air

• Smoke or fire might result from flammable gas, etc.

• Breakdown might result from corrosive gas or dust.

0305-001 50

Beware of gas around the device

CAUTION

Beware of Lamp Soot and Dust

CAUTION

Example: Injecting Flammable Gas, etc.

Smoking/

Injection

5.7 Install the device in clean air

Tg0869-PM-OM

0305-001 51

Example: Breakdown due to Corrosive Gas

CAUTION

Breakdown

5.7 Install the device in clean air
