Tg0869-PM-OM 5.3 Do not allow any blows to the Device • When the device is moved do not bump it. • • • • • Dangers caused by blows to the Device • Any impact to the device might cause damage or breakdown . 0305-001 46 Do…

Tg0869-PM-OM

0305-001 45

5.2 Install the device somewhere where the floor

strength is adequate

• Install the device on the floor which can support the device

weight.

First floor is recommended. In the case of installing the

device on the floor other than the first floor, consult our

marketing department or sales agency.

••

• Dangers caused by Inadequate Floor Strength

Check

• If the device is installed on the floor with inadequate strength,

it might fall and be damaged.

CAUTION

Install the Device on the First Floor

First Floor

CAUTION

Example: Falling due to Inadequate Floor Strength

Damage

Beware of Floor Strength

CAUTION

5.2 Install the device somewhere where the floor strength is

adequate

Tg0869-PM-OM

5.3 Do not allow any blows to the Device

• When the device is moved do not bump it.

••

• Dangers caused by blows to the Device

• Any impact to the device might cause damage or breakdown.

0305-001 46

Do not allow any blows to the device

Example: Impact during relocation or transport of the device

CAUTION

Damage

Breakdown

5.3 Do not allow any blows to the Device

Tg0869-PM-OM

5.4 Install the device somewhere where there is no

vibration

• Install the device somewhere where there is no vibration.

••

• Dangers caused by Vibration

• The device might fall or be damaged because of vibration.

• The device might break down because of vibration.

0305-001 47

Beware of Vibration

CAUTION

Example: Falling due to Vibration

Damage

Example: Breakdown due to Vibration

CAUTION

Breakdown

5.4 Install the device somewhere where there is no vibration
