Tg0869-PM-OM 0305-001 28 2.2 Always Check before Operation • Always check the device before automatic operation. • • • • • Dangers cause by Inadequate Safety Check • Smoke or fire might occur because a fault in the devic…
Tg0869-PM-OM
• Part of your body might be rolled into the rotation section of
the device, which might cause injury.
• The moving part of the machine might collide with another
part.
0305-001 27
WARNING
Example: Inadequate Safety Check
Injury
CAUTION
Example: Inadequate Safety Check
Collision
2.1 Safety Check before Operation
Tg0869-PM-OM0305-001 28
2.2 Always Check before Operation
• Always check the device before automatic operation.
••
••
• Dangers cause by Inadequate Safety Check
• Smoke or fire might occur because a fault in the device is not
found.
• Breakdown of the device might occur because a fault is not
found.
Example: Operation without Fault Finding
CAUTION
CAUTION
Check before Operation
Check
Example: Operation without Fault Finding
CAUTION
Smoking/
Injection
Breakdown
2.2 Always Check before Operation
Tg0869-PM-OM
2.3 Close the magazine door securely
• Press the black circle on the warning label attached to the maga-
zine door to close the door securely.
0305-001 29
••
••
• Dangers caused by Imperfect Closure of Maga-
zine Door
• If the magazine door is not securely closed, the door might
become deformed and open during operation, which might
cause breakdown.
Example: Collision caused by Imperfect Closure
of the Magazine Door
Collision
CAUTION
Collision
CAUTION
Close the Magazine Door Securely
2.3 Close the magazine door securely
Lock it securely
Magazine Door Side View
