Tg0869-PM-OM 5.4 Install the device somewhere where there is no vibration • Install the device somewhere where there is no vibration. • • • • • Dangers caused by V ibration • The device might fall or be damaged because o…
Tg0869-PM-OM
5.3 Do not allow any blows to the Device
• When the device is moved do not bump it.
••
••
• Dangers caused by blows to the Device
• Any impact to the device might cause damage or breakdown.
0305-001 46
Do not allow any blows to the device
Example: Impact during relocation or transport of the device
CAUTION
Damage
Breakdown
5.3 Do not allow any blows to the Device
Tg0869-PM-OM
5.4 Install the device somewhere where there is no
vibration
• Install the device somewhere where there is no vibration.
••
••
• Dangers caused by Vibration
• The device might fall or be damaged because of vibration.
• The device might break down because of vibration.
0305-001 47
Beware of Vibration
CAUTION
CAUTION
Example: Falling due to Vibration
Damage
Example: Breakdown due to Vibration
CAUTION
Breakdown
5.4 Install the device somewhere where there is no vibration
Tg0869-PM-OM
0305-001 48
5.5 Install the device somewhere where atmospheric
temperature and humidity is within the specified
range
• Install the device where atmospheric temperature range is 20 ±
10°C.
Also, install it where the humidity range is 20 to 80 % without
condensation.
••
••
• Dangers if atmospheric temperature or humid-
ity exceeds the specified range
• Smoke or fire might be caused by the device being at abnor-
mally high temperature.
CAUTION
Example: Smoke cause by abnormal heating
Smoking/
Injection
5.5 Install the device somewhere where atmospheric temperature
and humidity is within the specified range
Atmospheric
Temperature
20 ± 10°C
Atmospheric
Humidity
30 to 80%
Beware of Temperature and Humidity
CAUTION
